Utilitech 1310836UT4 Rotating Wireless Charging Pad User Manual

Quick Guide

The Utilitech Rotating Wireless Charging Pad allows you to charge Qi-compatible devices in either a flat or angled position. To use, connect the charging pad to a power adapter (not included) using the provided Micro-USB cable, place your device on the center of the pad, and ensure the LED indicator illuminates to confirm charging status.

Setup and Operation

Follow these steps to set up your charging pad:

1. Insert the USB end of the input cable into a power adapter (not included).
2. Insert the Micro-USB end of the charging cable into the port on the wireless charger.
3. Place your Qi-compatible phone on the center of the Wireless Charging Pad.
4. The LED indicator will illuminate automatically to indicate the charging status.

Charging Modes

The charging pad features a unique rotating design to accommodate different viewing angles:

• Angled mode: Hold the charger base firmly and twist the top clockwise to tilt the pad.
• Flat mode: Hold the charger base firmly and twist the top counterclockwise to return the pad to a flat position.

Safety Precautions

• Keep the charger away from water and other liquids.
• Only place Qi-compatible phones on the charger.
• Do not place metal or metallic objects on the charger, as this may interfere with charging or cause overheating.
• When cleaning the charger, ensure it is not connected to a power source. Wipe it gently with a soft, dry cloth.

Specifications

• Input: 5V/2A
• Standard Charging Output: 5W
• Fast Charging Output: Up to 9W (requires an adaptive fast charger)
• Charging Distance: ≤6mm

Package Contents

• Rotating Wireless Charging Pad
• Micro-USB Input Cable
• User Manual
