Bosch EasySander 18V-8 Cordless Multi-Sander User Manual

Quick guide from the manual

The Bosch EasySander 18V-8 is a cordless multi-sander designed for dry sanding of wood, plastic, metal, filler, and varnished surfaces. It is particularly suitable for profiles, corners, and hard-to-reach areas.

Assembly

Battery: Insert the charged battery into the battery holder until it clicks into place. To remove, press the battery release button and pull the battery out.

Dust Extraction: The tool features a built-in dust extraction system. Slide the dust box (5) onto the extraction outlet (10). To empty, rotate the box slightly and pull it back. Unscrew the filter element (11) to empty the box and clean the filter by tapping it on a solid surface or using a soft brush.

External Extraction: For external dust extraction, insert the dust extraction adapter (13) into an extraction hose (12) until it clicks. Connect the adapter to the extraction outlet (10) and the hose to a suitable vacuum cleaner.

Operation

Switching On/Off: To switch on, tilt the on/off switch (1) to the right to the “I” position. To switch off, tilt it to the left to the “O” position.

Overload Protection: The tool is equipped with temperature-dependent overload protection. If the tool is overloaded or the battery temperature exceeds the permitted range, the electronics will switch off the tool until it returns to the optimum operating temperature.

Sanding Sheet Replacement

The sanding plate (7) is equipped with a hook-and-loop fastening system. Before attaching a new sheet, remove dust and dirt from the plate. Ensure the holes in the sanding sheet align with the holes in the sanding plate for optimal dust extraction. The tool uses two sanding sheets that can be replaced individually.

Maintenance and Cleaning

Always remove the battery before performing any maintenance or changing accessories. Keep the tool and ventilation slots clean for safe and efficient operation.
