User Manual for EDEN 11530-EDAMZ Multi-Pattern Sprinkler Plus Misting System
Quick guide for the EDEN 11530-EDAMZ Multi-Pattern Sprinkler Plus Misting System. Learn how to set up the tripod, adjust spray patterns, control coverage distance, and use the Quick Connect system.
Table of contents
Manual images
Click an image to enlargeQuick Setup and Operation
The EDEN 11530-EDAMZ is a multi-pattern sprinkler system designed for versatile garden watering. To begin, place the tripod in your desired location and push the legs firmly into the ground until the spikes are fully seated. Attach the sprinkler head to the top of the tripod, ensuring it is secure but not overtightened. Connect your garden hose either directly or via the included Quick Connect system.
Tripod Installation
When setting up the tripod, follow the yellow warning sign located on the unit to avoid pinching your thumb while pushing the legs into the ground. Ensure the tripod is stable before attaching the sprinkler head.
Spray Pattern and Coverage Adjustments
You can customize the watering area using the following controls:
- Spray Pattern: Manually select from various settings: FLAT (flat wave), FAN (wide fan), MIST (cools small areas), LARGE (larger spray area), and MULTI (combination of patterns).
- Spray Coverage and Distance: Use the range tabs and angle cap to adjust the spray coverage from 5° up to 360°.
- Level Adjustment: Move the angle cap to control the distance. Higher levels create a higher arc for greater coverage, while lower levels reduce the watering area.
Using the Quick Connect System
The Quick Connect system simplifies the connection process and allows for easy swapping of watering tools. Connect the Product Adapter to the base of the sprinkler and attach the lockable Quick Connect to the end of your hose. Snap the hose onto the sprinkler to begin. This system allows the hose to swivel 360 degrees, preventing kinking and twisting.
Performance Specifications
Performance is measured at 40 PSI:
- Large Pattern: 39 ft (12 m) radius, up to 4860 sq ft (452 m²) coverage.
- Multi Pattern: 37 ft (11.5 m) radius, up to 4470 sq ft (415 m²) coverage.
- Flat Pattern: 29 ft (9 m) radius, up to 2730 sq ft (250 m²) coverage.
- Fan Pattern: 27 ft (8.5 m) radius, up to 2440 sq ft (226 m²) coverage.
Safety Information
This product contains chemicals, including styrene, which is known to the State of California to cause cancer. For more information, visit www.P65Warnings.ca.gov.
Official resources from the manual
Manufacturer information
Eden Garden
Practical help
Common problems
Sprinkler head is difficult to attach.
Ensure you are not overtightening the head onto the tripod.
Hose keeps kinking or twisting.
Use the included Quick Connect system, which allows the hose to swivel 360 degrees.
Before use
- Ensure the tripod legs are pushed firmly into the ground.
- Check for the yellow warning sign on the tripod to avoid pinching your thumb.
- Verify the sprinkler head is attached securely but not overtightened.
- Decide if you are using the Quick Connect system or connecting directly to the hose.
Specs in practice
- Radius of Spray
- The distance the water reaches from the sprinkler head.
- Coverage Area
- The total square footage or square meters the sprinkler can water.
Images and diagrams
- Tripod setup: Push legs into the ground until spikes are seated.
- Quick Connect: Snap the adapter onto the hose and then onto the sprinkler base.
- Level Adjustment: Use the angle cap to adjust the arc height for distance control.
Model compatibility
- Compatible with 5/8-inch and 1/2-inch garden hoses.
