Flama 2330FL Micathermic Heater User Manual
Quick guide for the Flama 2330FL Micathermic Heater. Learn how to assemble the feet, operate the thermostat, use power settings, and maintain your heater safely.
PDF source: Français · summary: English
Quick answers from the manual
Quick answer
- The Flama 2330FL is a micathermic heater. To operate, unwind the cord, plug it in, set the thermostat to MAX, and select the desired power level (I or II). p. 5, 10, 15, 20
Key actions
- Assemble the feet by screwing them into the bottom of the heater. p. 5, 10, 15, 20
- Set the thermostat to the anti-frost (*) position to activate protection below 5ºC. p. 5, 10, 15, 20
First start
- Unwind the power cord completely before plugging the appliance into a wall socket. p. 5, 10, 15, 20
Show 4 more answers Show less
Problems and fixes
Overheating
Turn off the heater and wait 30 minutes before turning it on again.
p. 4, 9, 14, 19Maintenance and reset
- Unplug the appliance and let it cool down before cleaning. Keep grilles clean of dust and lint. p. 5, 10, 15, 20
Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| Nominal heating output | 1.5 kW | Maximum power output | p. 6, 11, 16, 21 |
Where to find it in the PDF
- Safety Instructions p. 3, 8, 13, 18
- Description and Assembly p. 5, 10, 15, 20
- Technical Specifications p. 6, 11, 16, 21
Table of contents
Quick guide from the manual
The Flama 2330FL is a micathermic heater designed for indoor use. This guide covers the essential steps for assembly, operation, and maintenance to ensure safe and efficient use.
Description
The heater consists of the following components:
- 1. Grille
- 2. Power level selector
- 3. Thermostat control knob
- 4. Lighted indicator
- 5. Feet with caster wheels
- 6. Cord wrap
- 7. Handle
Assembling the feet
Before using the heater, you must attach the feet:
- Place the feet at both ends of the bottom part of the appliance.
- Align the openings on the feet with the hubs located underneath the appliance.
- Screw the feet securely into place.
Operating instructions
Follow these steps to operate the heater:
- Preparation: Fully unwind the power cord from the cord wrap.
- Connection: Plug the appliance into a wall socket.
- Initial Setup: Turn the thermostat control knob clockwise to the maximum (MAX) position.
- Power Selection: Set the power level selector to the desired position. The lighted indicator will turn on.
- Power Levels:
- Position 0: Off.
- Position I: Minimum power.
- Position II: Maximum power.
- Temperature Control: When the desired room temperature is reached, turn the thermostat control knob counterclockwise until the lighted indicator turns off. The thermostat will automatically maintain the selected temperature by cycling on and off.
Anti-frost function
To use the anti-frost function, set the thermostat control knob to the anti-frost (*) position and ensure the power level selector is activated. The appliance will automatically turn on if the ambient temperature drops below 5ºC.
Safety instructions
- Do not cover: To avoid overheating, never cover the heater.
- Placement: Always use the heater in an upright position. Do not place it near curtains, flammable objects, or products.
- Water safety: Do not use the radiator near showers, bathtubs, sinks, or swimming pools. Do not immerse in water or any liquid.
- Overheating protection: The heater has an integrated safety system. If it overheats, turn it off and wait about 30 minutes before restarting.
- Children: Keep children under 3 years old away unless supervised. Children between 3 and 8 years old should only operate the heater under supervision and when it is installed in its normal operating position.
Maintenance and cleaning
- Always unplug the appliance and let it cool down before cleaning.
- Keep the air intake and outlet grilles clean of dust and lint.
- Clean the exterior with a soft, dry cloth.
- Do not use chemical or abrasive products, or steel wool, as these can damage the surface.
Manufacturer information
FLAMA, SA
Practical help
Common problems
Heater stops working
The safety system may have triggered due to overheating. Turn the unit off, wait 30 minutes for it to cool, and then restart.
Heater does not turn on
Ensure the power cord is fully unwound and plugged into a working wall socket. Check that the thermostat is set correctly.
Before use
- Unwind the power cord completely from the cord wrap.
- Ensure the heater is placed in a vertical position.
- Verify that the voltage matches the rating plate.
- Check that the socket is properly earthed.
- Ensure the heater is not placed under a power socket.
Show more Show less
Specs in practice
- Nominal heating output
- 1.5 kW
- Anti-frost function
- Automatically activates heating if ambient temperature falls below 5ºC.
Images and diagrams
- The diagram shows the heater with numbered parts: 1 (Grille), 2 (Power selector), 3 (Thermostat), 4 (Indicator), 5 (Feet), 6 (Cord wrap), 7 (Handle).
Model compatibility
- The heater is designed for indoor use only.
- Do not use in bathrooms or near water sources.
