Installation and Operating Instructions for Hansgrohe ShowerSelect Comfort S, E, and Q
A comprehensive guide for installing and operating the Hansgrohe ShowerSelect Comfort S, E, and Q thermostatic shower mixers. Includes safety notes, technical specifications, temperature adjustment procedures, maintenance tips, and...
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
This document provides installation and operating instructions for the Hansgrohe ShowerSelect Comfort S (15559XX0), E (15574XX0), and Q (15588XX0) thermostatic mixers. Key requirements include ensuring equal pressure for hot and cold water supplies and flushing pipes before installation. The product is designed for drinking water and must be installed according to local plumbing codes.
Safety Notes
- Wear gloves during installation to prevent crushing and cutting injuries.
- The product is for bathing, hygienic, and body cleaning purposes only.
- Children and individuals with impairments must not use the product without supervision.
- Persons under the influence of alcohol or drugs are prohibited from using the product.
- Hot and cold supplies must be of equal pressure.
Installation Requirements
Before installation, inspect the product for transport damage. The pipes and fixture must be installed, flushed, and tested according to applicable standards. If using power tools, wear safety glasses and disconnect the power supply after use. The unit must be mounted on a finished, waterproofed wall surface.
Operation and Adjustment
Safety Function: The desired maximum temperature (e.g., 42°C) can be pre-set using the safety function. If a higher temperature is required, the safety stop can be overridden by depressing the safety button.
Temperature Adjustment: After installation, the output temperature must be checked. If the measured output temperature differs from the set temperature, a correction is necessary. Follow the adjustment steps provided in the assembly diagrams.
Maintenance
- Check Valves: Must be checked regularly according to EN 806-5 (at least once a year).
- Thermostat Care: To ensure smooth operation, periodically turn the thermostat from total hot to total cold.
- Cleaning: Do not use silicone containing acetic acid. Refer to the cleaning recommendations provided by Hansgrohe.
Troubleshooting
- Insufficient water: Check supply pressure and clean the regulator filter or shower filter seal.
- Crossflow: Clean or exchange the backflow preventer cartridge.
- Temperature mismatch: Adjust the thermostat or increase hot water temperature to 42°C - 60°C.
- Temperature regulation not possible: Exchange the thermo cartridge or check if the basic body is connected correctly (cold right, hot left).
- Safety stop button not operating: Clean the spring or button and grease lightly.
Technical Data
Operating pressure is max. 1 MPa (recommended 0.1 - 0.5 MPa). Hot water temperature is max. 60°C. Thermal disinfection is possible at 70°C for 4 minutes. The product features safety against backflow.
Manufacturer information
Hansgrohe SE
Practical help
Common problems
Insufficient water flow
Check supply pressure, clean the regulator filter in front of the mixer, and clean the shower filter seal.
Crossflow (hot water in cold pipe or vice versa)
Clean or exchange the backflow preventer cartridge.
Output temperature does not match set temperature
Adjust the thermostat or increase the hot water supply temperature to between 42°C and 60°C.
Temperature regulation not possible
Exchange the thermo cartridge or check if the basic body was installed with 180° rotation.
Safety stop button not operating
Clean the spring or button and grease lightly; replace the handle if necessary.
Before use
- Inspect the product for transport damage.
- Flush the pipes and fixture according to applicable standards.
- Ensure hot and cold water supplies have equal pressure.
- Check for hidden pipes and cables in the wall before drilling.
- Verify that the wall surface is finished and waterproofed.
- Ensure the water supply system (Gas boiler, Unvented, or Pumped) is compatible.
Specs in practice
- Operating pressure
- Maximum 1 MPa (10 bar). Recommended range is 0.1 - 0.5 MPa.
- Hot water temperature
- Maximum 60°C.
- Thermal disinfection
- Can be performed at 70°C for 4 minutes.
Images and diagrams
- Assembly diagrams (pages 9-17) detail the installation, temperature calibration, and maintenance steps.
- Flow diagram (page 18) illustrates the flow characteristics for outlets 1 and 2.
- Spare parts diagram (page 19) identifies components for repair and maintenance.
Model compatibility
- Suitable for Gas Combination Boilers (multi-point), Unvented Systems (pressure balanced), and Pumped Systems.
- For gravity-fed systems, a minimum head (vertical distance) of 5 meters from the cold water storage tank to the showerhead is required.
- If pressure exceeds 3.5 bar, a pressure-reducing valve should be fitted.
