Husqvarna 125B & 125BVX Blower/Vacuum User Guide
Quick guide for the Husqvarna 125B and 125BVX blower/vacuum, covering assembly, operation, maintenance, and safety instructions.
Table of contents
Quick guide from the manual
This document provides essential instructions for the Husqvarna 125B and 125BVX blower/vacuum. Key operations include proper fuel mixing (50:1 ratio), starting procedures for cold and warm engines, and assembly of the blower and vacuum attachments. Always wear appropriate personal protective equipment, including eye, ear, and respiratory protection, and maintain a safe distance of at least 15 meters from bystanders.
Device Overview
The product consists of a fan housing, engine, and various attachments. Key components include the throttle trigger, stop switch, speed control, air filter, choke, primer bulb, and fan impeller. Depending on the model, it may include a vacuum handle, cutters, and collection components.
Assembly
Blower Tube and Nozzle: Align the rib on the upper blower tube with the groove in the blower outlet and secure it by turning the bolt clockwise. Align the slots on the lower blower tube with the tabs on the upper tube and rotate clockwise until it clicks.
Vacuum Tubes: Release the latch on the vacuum inlet using a screwdriver. Align the ribs on the inlet with the slots on the upper vacuum tube, ensuring the lock symbol aligns with the unlock symbol, then rotate clockwise until it clicks.
Operation
Fuel: Use a mixture of gasoline (minimum 90 RON/87 AKI, max 10% ethanol) and high-quality two-cycle engine oil at a 50:1 (2%) ratio. Do not use leaded gasoline.
Starting: Fill the fuel tank, press the primer bulb 10 times, set the choke to full, and pull the starter rope handle until the engine attempts to start. Move the choke to the 1/2 position and pull until the engine starts. Warm up for 1 minute before use.
Maintenance
Follow the maintenance schedule based on daily use. Daily tasks include cleaning external surfaces, checking throttle and speed control, and inspecting the air filter. Weekly tasks include cleaning the spark plug, checking the spark arrester screen, and cleaning the impeller blades. Monthly and yearly tasks involve more thorough cleaning and inspection of fuel lines, filters, and cables.
Safety
Always operate on safe, level surfaces. Do not use the product indoors or near flammable materials. Keep bystanders at least 15 meters away. Always wear approved eye, ear, and respiratory protection. Stop the engine before performing any maintenance or clearing blockages.
Manufacturer information
Husqvarna
Practical help
Common problems
Engine is low on power or hard to start
Check the spark plug for dirt or damage, ensure the air filter is clean, and verify the idle speed is correctly adjusted.
Engine stops during operation
Move the choke control to the closed position and repeat the starting steps.
Excessive vibration
Check the impeller for debris or damage and ensure all nuts and screws are tightened.
Before use
- Examine the product for missing, damaged, loose, or worn parts.
- Check the collection bag for damage and ensure the zipper is closed.
- Verify all nuts, screws, and bolts are tight.
- Inspect the air filter.
- Check the throttle trigger and stop switch for correct operation.
- Inspect the product for fuel leaks.
Specs in practice
- Cylinder displacement
- 28 cm³ for both 125B and 125BVX models.
- Fuel tank volume
- 500 cm³.
- Mixture ratio
- 50:1 (2%) using high-quality two-cycle engine oil.
Images and diagrams
- The diagram shows the assembly of the blower and vacuum components, including the fan housing, tubes, and collection bag.
- Numbered parts identify components like the throttle trigger, stop switch, fuel tank cap, and air filter.
Model compatibility
- 125BVX includes a shoulder strap, vacuum handle, and cutters.
- 125B and 125BVX are compatible with the gutter clean-out kit (952 711 918) and vacuum kit (952 711 913).
- High velocity nozzle (545 119 501) is an approved accessory for the 125B.
