User Manual for Hygger HG-044 Aquarium Filter
Quick guide for the Hygger HG-044 3-in-1 internal aquarium filter. Learn how to install, assemble, maintain, and safely operate your filter for optimal water quality.
Table of contents
Quick guide from the manual
This 3-in-1 internal aquarium filter provides oxygenation, filtration, and bacteria cultivation. Note: This product requires an external air pump and air tubing, which are not included in the package. Ensure the filter is fully submerged during operation.
Product Overview
The filter consists of the following components:
- (1) Black shell
- (2) Air outlet
- (3) Oxygenation pipe interface
- (4) Suction cup
- (5) Filter box
- (6) Plastic clapboard
- (7) Filter cotton
- (8) Filter stone
- (9) Filter box cover
Installation Instructions
- Separate the filter box from the black shell and open the filter box cover.
- Place the filter cotton into the bottom of the filter box and fix the plastic partition board on top of the cotton.
- Take out the filter stone and pour it into the filter box.
- Cover the lid of the filter box and reattach it to the black shell. Install the suction cup on the black shell.
- Connect the air pump to the filter using the oxygenating tube.
- Place the filter at the bottom of the aquarium and use the suction cup to stabilize it against the tank wall.
- Turn on the air pump to begin operation. Ensure the filter is fully submerged and there is sufficient water flow.
Safety and Maintenance
- Keep the device out of the reach of children.
- Ensure the filter is fully submerged and there is sufficient water flow and circulation in the tank.
- Check for air leakage when connecting the tubing.
- Clean the internal components regularly to remove debris.
- Do not use the product in flammable or corrosive liquids.
- Do not use in water that is too hot or too cold (over 36°C or below 0°C) as it may damage the material.
- Always turn on the air pump after the filter is placed in the tank.
- Turn off the air pump before replacing or removing the filter.
Disposal
Do not dispose of this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. Please consult with your local seller to ensure the product is disposed of in an environmentally friendly way.
Contact Information
E-mail: [email protected]: www.hygger-online.com
Official resources from the manual
Manufacturer information
Hygger Aquarium Inc
Practical help
Common problems
Filter not producing bubbles
Ensure the air pump is turned on and the filter is fully submerged in the water.
Air leakage
Check all connections between the air pump and the oxygenating tube.
Before use
- Ensure you have an external air pump and air tubing (not included).
- Check that the filter is fully submerged in the tank.
- Verify the water temperature is between 0°C and 36°C.
- Clean the filter box components before first use.
Specs in practice
- Operating Temperature
- 0°C to 36°C. Do not use in water outside this range to prevent material damage.
Images and diagrams
- The diagram illustrates the assembly of the filter box, including the placement of the filter cotton, plastic clapboard, and filter stone.
- The suction cup is attached to the black shell to secure the unit to the aquarium wall.
Model compatibility
- Requires an external air pump and air tubing, which are not included in the package.
