Somogyi FLB 10C Rechargeable COB LED Floodlight
Instruction manual for the Somogyi FLB 10C weather-resistant, portable, rechargeable COB LED floodlight with magnetic fold-out frame and dual light sources.
Table of contents
Product Overview
The Somogyi FLB 10C is a weather-resistant, battery-powered LED floodlight designed for maximum mobility and versatility. It features a strong magnetic, fold-out, and foldable carrying frame that allows for various fastening, hanging, and support configurations. The unit is equipped with two separately movable light sources, which can be adjusted to illuminate in different directions. Users can operate one light source, the other, or both simultaneously, with options for maximum or reduced brightness.
Installation and Use
The luminaire is delivered fully assembled and does not require installation. To charge the device, use the provided micro-USB cable with a 5 V / min. 1 A USB adapter (not included). The luminaire cannot be used while charging. Charging status is indicated by LEDs: flashing red during charging and solid green when fully charged. Once charged, ensure the charging socket is sealed with the rubber tab to maintain weather resistance.
The light is controlled via a button on the back, cycling through the following modes:
- Both light sources at 100% brightness (10 W / 1000 lumen)
- Both light sources at 50% brightness (5 W / 500 lumen)
- One light source at 100% brightness (5 W / 500 lumen)
- The other light source at 100% brightness (5 W / 500 lumen)
- Turning off
Additionally, the luminaire features a USB-A socket that can be used to charge external devices.
Cleaning and Maintenance
To ensure optimal performance, clean the unit at least once a month depending on usage. Power off the device before cleaning. Use a slightly moistened cloth to wipe the outer surface. Do not use aggressive cleaning agents, and ensure no water enters the unit or reaches electrical components. Always ensure the insulating rubber feet are correctly positioned.
Safety and Disposal
Do not stare directly into the LED light. The protective shield is not replaceable; if it becomes cracked or broken, the entire product must be discarded. Maintain a minimum distance of 0.5 meters from the illuminated surface. This product contains hazardous components and must be disposed of separately from household waste at designated electronic waste collection facilities. Batteries and accumulators must also be disposed of according to local environmental regulations.
Manufacturer information
Somogyi Elektronic Kft.
Practical help
Common problems
The lamp is not lighting.
Check the switch on the back of the lamp and charge the battery if necessary.
Before use
- Ensure the device was not damaged during transport.
- Acquire a 5 V / min. 1 A USB adapter for charging.
- Verify the protective shield is intact.
- Ensure the insulating rubber feet are in place.
Images and diagrams
- 1. Foldable carrying frame with integrated magnets.
- 2. Two adjustable COB LED light heads.
- 4. Push-button for mode selection.
- 5. Micro-USB charging socket.
- 6. USB-A output socket for charging external devices.
Model compatibility
- Requires a 5 V / min. 1 A USB adapter for charging (not included).
- Compatible with external devices via the USB-A output socket.
