User Guide for Turtle Beach VelocityOne Race Universal Wheel and Pedal System

Quick Guide

The VelocityOne Race system requires a specific setup sequence to ensure proper functionality. First, mount the wheelbase to your desk or rig. Attach the VelocityOne Control Unit (VCU) to the side of the wheelbase, then attach the Race Wheel Module. Connect the cables to your console or PC, power on the system, and select your platform using the E2 wheel. Finally, use the VelocityOne Tuner app to customize settings and keep firmware updated.

Product Overview

The system consists of the following main components:

• Race Wheel Module
• VelocityOne Control Unit (VCU)
• Race Wheelbase
• Pedal Unit
• Power Supply Unit
• Various cables (VCU, Pedal, Xbox/PC)

Mounting the System

The wheelbase can be mounted in two ways:

• Desk/Table Mounting: Use the integrated clamp system. Ensure the wheelbase is securely tightened to the surface. Do not over-tighten.
• Hard Mounting: Use the provided M5 screws to secure the wheelbase and pedal unit to a racing rig or frame.

Attaching the VCU and Wheel

For ease of assembly, attach the VCU before the wheel module:

1. Remove the two M3 fastening bolts from the front of the wheel base.
2. Slide the VCU bracket into the desired slot on the side (can be configured for left or right-hand mounting).
3. Secure with the two M3 bolts.
4. Connect the VCU cable to the side USB port on the wheel base and the USB port on the back of the VCU.
5. Attach the Race Wheel Module to the wheelbase by aligning and locking it into place.

Connecting to Console or PC

Connect the components as follows:

• Connect the Power Supply Unit to the 24V DC IN port on the wheelbase.
• Connect the Pedal Unit to the wheelbase using the provided Pedal Cable.
• Connect the wheelbase to your Xbox or PC using the Xbox/PC Cable.
• If using a headset with a 3.5mm connection, plug it directly into the port on the wheelbase.

Adjusting the Pedal Unit

The pedal unit is highly customizable:

• Pedal Resistance: Adjust the spring tension to suit your driving style.
• Pedal Plates: The position of the pedal plates can be adjusted.
• Stow Clutch: The clutch pedal can be stowed away if not in use.
• Move Brake Pedal: The brake pedal position can be shifted laterally.

Powering On and Platform Selection

On the first power-on, you must select the correct platform:

1. Connect the system via USB.
2. Press and hold the Power button (on the VCU) for 2 seconds to turn on.
3. Use the E2 wheel and SELECT button to choose your platform (Xbox or PC).
4. Your choice is saved for future use. You can change this later via the 'Platform' menu on the RMD.

Race Management Display (RMD)

The RMD provides real-time telemetry and tuning features:

• Navigate the menu using the E2 wheel.
• Confirm selections with the SELECT button.
• Go back using the BACK button.
• To enable live telemetry, select the 'LIVE OUTPUT' option in the RMD menu.

VelocityOne Tuner App

Use the VelocityOne Tuner app (available on Microsoft Store, Play Store, and App Store) to:

• Customize performance settings.
• Adjust on-board memory profiles.
• Keep the system firmware up to date.

Safety Information

The VelocityOne Race features a high-fidelity direct drive motor (K:Drive). Please observe the following:

• Do not attempt to stop the wheel with your hands during high-force events (e.g., crashes).
• Use the K:DRIVE STOP button on the VCU or the K:DRIVE button on the wheelbase to instantly cut power.
• Avoid extended gameplay sessions; take 10-15 minute breaks.
• Ensure the wheelbase is securely attached to a surface.
• This is not a toy; keep away from small children.
