User Guide for VEVOR 1206MX-4301 D.C. Motor Controller
Quick guide for the VEVOR 1206MX-4301 D.C. Motor Controller, including installation, pin definitions, and safety precautions.
Table of contents
Manual images
Jump to the sectionQuick guide from the manual
This document provides essential information for the VEVOR 1206MX-4301 D.C. Motor Controller. It is designed for use with 2000-2009 EZGO TXT Golf Carts and is compatible with the 1206MX-4301 Curtis Controller 36V 350A. Users should read all instructions carefully before operation to ensure safety and proper functionality.
Device Description
The controller features high-power MOSFETs for efficient, quiet operation. It includes stepless speed regulation, reverse connection braking, and comprehensive temperature protection. It also provides undervoltage and overvoltage protection to ensure stable output and battery longevity.
Installation and Unpacking
Upon unpacking, verify that you have received the D.C. Motor Controller and the User's Guide. The device is designed for easy installation and direct replacement of the old controller. Ensure the controller is securely fixed and protected from vibration or impact during installation.
Pin Chart and Port Definition
The controller features multiple ports for connection:
- A port: Includes relay microcurrent, keyswitch, reversing buzzer connections, forward/backward switch lines, and a 36V charging socket.
- C port: Manages Switch 1 and Switch 2 inputs/outputs.
- D port: Handles short wiring and accelerator signals.
- E port: Manages sensor negative electrode, signal output, and positive electrode.
Safety and Maintenance
Do not disassemble the controller, as it contains high-voltage components that pose a danger. The manufacturer is not responsible for losses caused by failure to follow these instructions. This product is subject to European Directive 2012/19/EC regarding the separate collection of electrical and electronic waste.
Technical Specifications
- Model: 1206MX-4301
- Voltage: 36V
- Current: 350A
Manufacturer information
VEVOR
Practical help
Common problems
Controller not working after installation
Verify all pin connections (A, C, D, E ports) against the pin chart and ensure the controller is securely fixed.
High voltage danger
Do not disassemble the controller case under any circumstances.
Before use
- Check for any missing or damaged parts upon unpacking.
- Ensure the controller is compatible with your 2000-2009 EZGO TXT Golf Cart.
- Verify that the controller is securely mounted to prevent vibration or impact damage.
- Read all safety instructions carefully before operating.
Specs in practice
- Current: 350A
- The maximum current capacity of the controller.
Images and diagrams
- The pin chart shows the physical layout of ports A, C, D, and E on the controller.
- Port A handles power and switching signals.
- Port C handles switch inputs/outputs.
- Port D handles accelerator signals.
- Port E handles sensor signals.
Model compatibility
- Designed to fit 1206MX-4301 Curtis Controller 36V 350A.
- Compatible with 2000-2009 EZGO TXT Golf Carts.
