User Manual for VEVOR 2022FKB Stair Climbing Cart
Quick guide for the VEVOR 2022FKB Stair Climbing Cart. Includes assembly instructions, safety warnings, load capacities, and maintenance tips.
Quick answers from the manual
Quick answer
- The VEVOR 2022FKB is a stair climbing cart with a maximum load capacity of 260 lbs on flat ground and 120 lbs on stairs. p. 3
Key actions
- Unfold the frame and install the universal wheels at the front end of the tray bottom using the provided bolts and nuts. p. 6
Problems and fixes
Tray breakage
Do not shovel lifting objects directly horizontally.
p. 3Maintenance and reset
- Avoid prolonged sun exposure and fold the cart when not in use for long periods. p. 6
Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| Maximum Load (Flat Ground) | 260 lbs | Weight limit on level ground | p. 3 |
| Maximum Load (Climb Stairs) | 120 lbs | Weight limit on stairs | p. 3 |
Where to find it in the PDF
- Safety Instructions p. 3
- Structure Diagram p. 4
- Assembly p. 6
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
The VEVOR 2022FKB is a stair climbing cart designed for transporting goods. It features a foldable frame and specialized wheels for navigating stairs. Always adhere to the weight limits to ensure safe operation.
Key Specifications
- Maximum Load (Flat Ground): 260 lbs
- Maximum Load (Climbing Stairs): 120 lbs
- Material: Steel + TPR + PP
Safety Instructions
WARNING: Failure to follow these instructions may result in damage to the product or injury.
- Do not place the cart near flammable materials.
- Transporting people is strictly forbidden under any conditions.
- Exercise caution when going up and down stairs.
- Overloading is strictly prohibited.
- Do not move too fast when passing over potholes or uneven surfaces.
- Do not shovel lifting objects directly horizontally to avoid breaking the tray.
Assembly
1. Unfold the frame (A).
2. Install the two universal wheels (B) at the front end of the tray bottom using the provided bolts (C) and nuts (E).
Maintenance
- Avoid prolonged exposure to the sun to prevent material aging.
- Fold the cart when not in use for an extended period.
- Keep the cart away from children to prevent them from using it as a toy.
Manufacturer information
VEVOR
Practical help
Common problems
Tray breakage
Do not shovel lifting objects directly horizontally onto the tray.
Overloading
Ensure the load does not exceed 260 lbs on flat ground or 120 lbs on stairs.
Before use
- Ensure the cart is fully unfolded and locked.
- Verify that the universal wheels are securely attached with bolts and nuts.
- Check that the load is within the specified weight limits.
- Inspect the path for large potholes or obstacles.
Specs in practice
- Maximum Load (Flat Ground)
- The maximum weight the cart can carry on level surfaces is 260 lbs.
- Maximum Load (Climbing Stairs)
- The maximum weight the cart can carry while navigating stairs is 120 lbs.
Images and diagrams
- 2. Push Button
- 4. Rotating Shaft
- 5. Universal Wheel
- 7. Climbing Wheel
Model compatibility
- Designed for use on stairs and flat ground.
- Not intended for transporting people.
