User Manual for Whirlpool 9KG Washing Machine

Quick guide from the manual

This guide provides essential information for operating your Whirlpool 9KG washing machine. Before using the appliance, ensure that the transport bolts are removed as per the installation guide. Always read the Health and Safety guide before operation.

Control Panel

The control panel allows you to manage all washing functions:

• ON/OFF button: Switches the machine on and off.
• Programme selector: Used to choose the desired wash cycle.
• Temperature button: Adjusts the wash temperature.
• Spin button: Adjusts the spin speed.
• Start delay button: Sets a delayed start time.
• Start/Pause button: Starts or pauses the selected programme.
• Key lock button: Locks the control panel to prevent accidental changes.

Programme Chart

The machine offers various programmes tailored to different fabric types and soil levels. Key programmes include:

• Eco 40-60: The standard efficient programme for normally soiled cotton garments.
• Mixed: For lightly to normally soiled resilient garments.
• Whites: For heavily soiled towels and linens.
• Steam Refresh: Refreshes garments by removing odors (max 2kg).
• Rapid 30min: A quick cycle for lightly soiled garments.

6th Sense technology: The sensor technology automatically adapts water, energy, and programme duration to your wash load.

Detergent Dispenser

The dispenser has three compartments:

• Main wash compartment (II): For detergent, stain remover, or water softener. Use the removable plastic partition for liquid detergent.
• Prewash compartment (I): For detergent used in the prewash phase.
• Softener compartment: For fabric softener or liquid starch. Do not exceed the 'max' mark.

Daily Use

1. Sort your laundry according to fabric type and care labels.
2. Load the laundry, close the door, and open the water tap.
3. Press the ON/OFF button.
4. Select the desired programme using the selector.
5. Adjust temperature and spin speed if necessary.
6. Add detergent and additives to the dispenser.
7. Press the Start/Pause button to begin the cycle.

Cleaning & Maintenance

Regular maintenance ensures optimal performance:

• Cleaning the water filter: If the machine fails to drain, the filter may be clogged. Place a container beneath the filter, turn it counterclockwise to drain residual water, then remove and clean it under running water.
• Cleaning the outside: Use a soft damp cloth. Do not use abrasive cleaners on the control panel.
• Descale: Run an automatic cleaning cycle roughly every 50 cycles to combat limescale and odors.

Troubleshooting

Before calling support, check the following:

• Machine does not turn on: Check the power plug and for power failures.
• Cycle does not start: Ensure the door is fully closed, the Start/Pause button is pressed, and the water tap is open.
• No water / Beep sound: Check if the water hose is bent or the tap is closed.
• Excessive vibration: Ensure the machine is level and transport bolts were removed during installation.
