User Manual for Avanti PDR36L34G / PDR50L34G Portable Refrigerator

Quick guide from the manual

This portable refrigerator is designed for mobile use in RVs, trucks, motorhomes, and campers. Before connecting the unit to a power source, let it stand upright for approximately 2 hours to allow the cooling system to stabilize. The unit can operate on 12V DC (battery) or 115V AC (using the provided adapter). Always ensure proper ventilation by maintaining at least 5 inches of space around the back and sides of the appliance.

Installation

Place the refrigerator on a surface strong enough to support it when fully loaded. Ensure the area is well-ventilated and protected from elements like rain, wind, or direct sunlight. The unit must be leveled for proper operation.

Electrical Connection

12V DC Power: Use the provided 12V DC cable. If the fuse blows, replace it with a 10A fuse.

115V AC Power: Use the provided AC adapter for initial cooling or when connected to a standard wall outlet. The unit requires a grounded 115V/60Hz outlet.

Operating Your Appliance

Temperature Control: Press the + or - buttons to set the desired temperature. Press the SET button to switch between zones. The temperature range is -4°F to 68°F (-20°C to 20°C).

Cooling Modes: Press the SET button to enter mode selection. Choose between MAX (Normal Cooling) or ECO (Energy Saving). The factory default is MAX.

Dry Storage Mode: To deactivate the cooling system, press and hold the + and SET buttons simultaneously until the display shows (- - -).

USB Connector: Provides +5V DC/1A output for charging small devices like mobile phones or tablets.

Battery Protection Mode

To protect your vehicle battery, the unit features a battery protection setting. Press and hold the SET button until the screen flashes to enter this menu. Press SET again to select:

• H (High): Recommended when connected to a car power source.
• M (Medium): For use with a portable battery.
• L (Low): For use with a portable battery.

If an F1 error code appears, adjust the protection mode from H to M or M to L.

Care and Maintenance

Cleaning: Unplug the unit. Wash the interior with a solution of 2 tablespoons of baking soda per quart of warm water. Clean the exterior with mild detergent and warm water.

Defrosting: If frost forms, turn off the unit, remove contents, and allow it to melt naturally. Do not use sharp objects to remove frost. Remove the drain plug to drain excess water.

Troubleshooting

If the unit does not operate, check if it is plugged in or if the circuit breaker has tripped. If the unit is not cold enough, ensure the door is closed properly and the temperature is set correctly. For error codes F1 through F8, refer to the troubleshooting section in the manual; most electronic errors (F2-F6) require disconnecting the unit for 30 minutes before restarting.
