Bestway Fast Set Pool and Filter Pump Owner's Manual
A complete owner's manual for Bestway Fast Set Pools and the included filter pump. This guide covers essential setup, safety warnings, water maintenance, filter pump installation, and winter storage procedures.
Quick answers from the manual
Quick answer
- To set up your Bestway Fast Set Pool, place it on a flat, level surface, fill to 80% capacity, and smooth out wrinkles from the center outwards. For the filter pump, fix it to a pedestal, connect hoses, and purge air using the top valve before starting. p. 2, 4, 10, 11
Key actions
- Smooth out pool floor wrinkles p. 2
- Fix filter pump to pedestal p. 10
- Clean filter cartridge p. 11, 13
First start
- Fill pool to 80% capacity p. 5
- Purge air from filter pump p. 11
Problems and fixes
Pool not level
Drain water and re-level ground by digging out.
p. 5Maintenance and reset
- Replace filter cartridge every two weeks p. 11
Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| pH value | 7.4 - 7.6 | Ideal chemical balance | p. 5 |
| Free chlorine | 2 - 4 ppm | Ideal sanitation level | p. 5 |
Where to find it in the PDF
- Pool Setup and Safety p. 2, 4, 5
- Filter Pump Installation p. 10, 11
Table of contents
Manual images
Click an image to enlargeQuick Guide from the Manual
This manual provides instructions for both the Bestway Fast Set Pool and the included filter pump. Key takeaways include:
- Safety First: Continuous adult supervision is required. Never dive into the pool. Keep chemicals out of reach of children.
- Setup: The pool must be placed on a completely flat, level surface. Do not install on sloped ground, driveways, or decks.
- Maintenance: Regularly test water chemistry (pH 7.4-7.6, Free Chlorine 2-4 ppm) and clean the filter cartridge daily.
- Filter Pump: Do not run the pump dry. Ensure the air purge valve is used during startup.
Pool Setup
Installation takes approximately 10 minutes with 2-3 people. Ensure the location is flat, level, and free of debris.
- Smoothing the Bottom: Fill the pool with 1 to 2 inches of water to cover the floor. Gently smooth out all wrinkles, starting from the center and working clockwise to the outside.
- Filling: Fill the pool until water capacity is 80%. Do not overfill, as this may cause the pool to collapse.
- Leveling: If the pool is not level, drain the water and re-level the ground by digging out. Never attempt to move the pool while it contains water.
Pool Maintenance
Proper maintenance is essential for water safety and pool longevity.
- Water Chemistry: Regularly check and adjust pH and chlorine levels. Ideal values: pH 7.4-7.6, Cyanuric acid 30-50 ppm, Free chlorine 2-4 ppm, Calcium hardness 200-400 ppm.
- Cleaning: Skim the pool regularly, cover when not in use, and clean the filter cartridge daily.
- Chemicals: Store chemicals out of reach of children and follow professional instructions for water treatment.
Filter Pump Installation
The filter pump must be installed correctly to ensure safe operation.
- Pedestal Fixing: The pump must be vertically fixed on a pedestal (wood or concrete) before use. Use two 9mm diameter holes spaced 127mm apart. The pedestal must weigh over 18kg.
- Hose Connection: Connect the hoses to the pool's inlet and outlet valves. Ensure hydraulic connectors are not closed.
- Operation: Open the air purge valve on top of the pump to release air as water fills the pump. Once water comes out, screw it closed.
Filter Pump Maintenance
Always unplug the pump before performing maintenance.
- Cleaning the Cartridge: Unplug the pump, stop water flow using stopper plugs, remove the filter cap, and clean the cartridge with a garden hose. Replace the cartridge every two weeks for sanitary reasons.
- Storage: During winter, disassemble the pool and pump. Store all components in a dry place with a temperature between 5°C and 38°C.
Manufacturer information
Bestway
Practical help
Common problems
Pool is not level
Drain the water and re-level the ground by digging out. Do not move the pool while filled.
Pool walls bulging or uneven
The pool is not level. Drain immediately to prevent bursting and potential injury.
Filter pump not working / air in system
Open the air purge valve on top of the pump to release trapped air until water flows out.
Water quality issues
Check pH and chlorine levels weekly and adjust to ideal values. Clean filter cartridge daily.
Before use
- Ensure the ground is flat, level, and free of debris.
- Verify the location has adequate drainage.
- Check that the filter pump is placed on a solid, level pedestal.
- Ensure all hoses are connected and valves are open.
- Have a bucket of water nearby to clean feet before entering.
- Ensure chemicals and pH test kits are available.
Specs in practice
- Free chlorine
- Ideal range 2-4 ppm for sanitation.
- Cyanuric acid
- Ideal range 30-50 ppm.
- Calcium hardness
- Ideal range 200-400 ppm.
Images and diagrams
- Smoothing the pool floor: Start from the center and work outwards.
- Pedestal fixing: Secure the pump to a base using M8 bolts and nuts.
- Air purge valve: Open to release air during startup.
- Hose connection: Ensure clamps are tightened and debris screens are in place.
Model compatibility
- Filter pump is for use with storable pools only.
- Do not use with permanently-installed pools.
- Ladder must match the pool size.
