User Manual for Denali 18V Brushless 400 CFM Leaf Blower

Quick guide from the manual

This leaf blower is designed for private use to blow dry leaves and garden debris. Before use, ensure all parts are inspected for damage and that the battery is charged. Always wear appropriate personal protective equipment, including eye and hearing protection. Remove the battery pack before performing any assembly, adjustments, or maintenance to prevent accidental starting.

Product description

The blower consists of the following main components:

• A: Blower tube
• B: Tube release button
• C/G: Ventilation slots
• D: On/off dial with variable speed function
• E: Antistatic wire
• F: Storage hook
• H: Nozzle
• I: Storage rail

Assembly

Tube Assembly: Align the groove in the tube (A) with the knob on the blower housing and push until it snaps into place. To attach the nozzle (H), align the lock lever with the knob on the tube (A) and push until it snaps into place.

Battery Installation: Align the ribs of the battery pack with the mounting slots in the blower's battery port and press until it snaps into position.

Operation

Start/Stop: Turn the on/off dial (D) to "1" to switch the blower on. Adjust the air flow by turning the dial between "1" and "Max". Turn the dial to "0" to switch off. Note that the motor may continue to run for a few seconds after switching off.

Usage Tips: Always hold the blower by the grip area. To prevent scattering debris, blow around the outer edges of a pile rather than directly into the center. Limit the number of pieces of equipment used at any one time to reduce noise levels.

Cleaning and maintenance

Cleaning: Always remove the battery pack before cleaning. Keep the machine clean, especially the ventilation slots (C). Wipe the surface with a dry cloth. Do not use solvents on plastic parts as they may cause damage.

Storage: Remove the battery pack. Clean foreign material from air inlets. Store indoors in a dry place, inaccessible to children. Use the provided storage rail (I) to hang the blower horizontally on a wall.

Troubleshooting

If the blower does not work, ensure the battery is attached, contacts are clean, and the battery is charged. If the blower or battery is too hot, allow them to cool down. If the air velocity decreases, check for a blocked air inlet or excessive fan wear. For internal defects, contact a professional repair center.

Specifications

Model: ABL4714B-00ERated voltage: 18 V (max. 20 V)Air volume: 680 m³/hAir speed: 160 km/hNet weight: approx. 1.95 kg (without battery, with tube and nozzle)
