User Guide for Dogtra ARC 1200S Dog Training Collar
Quick guide for the Dogtra ARC 1200S electronic training collar, covering setup, stimulation levels, charging, and troubleshooting.
Table of contents
Manual images
Jump to the sectionQuick guide from the manual
This document provides essential instructions for operating the Dogtra ARC 1200S training collar. Key procedures include pairing the transmitter and receiver, adjusting stimulation levels (0-127), and proper collar fitting to ensure effective training and skin safety. Always start at the lowest stimulation level and increase gradually based on your dog's reaction.
Device Overview
The system consists of a handheld transmitter and a receiver collar. The transmitter features a rheostat dial for precise stimulation control, buttons for Nick (short pulse), Constant (continuous pulse), and Pager (vibration) modes, and an LCD screen for status monitoring.
Setup and Operation
To turn on the transmitter, press the blue button on the side until the LCD screen lights up. To turn on the receiver, press the blue button until the LED indicator glows green. To turn off, repeat the process until the LED glows red and turns off. The collar must be fitted snugly enough that the contact points touch the dog's skin, but loose enough to allow one finger to pass between the strap and the neck.
Stimulation and Training
The ARC 1200S offers Nick (short pulse), Constant (continuous pulse), and Pager (vibration) modes. The stimulation level is adjustable from 0 to 127. If the constant button is held for more than 12 seconds, the device will automatically shut off for safety. Always consult a professional dog trainer if you are unsure about training methods or if your dog displays aggressive behavior.
Charging and Maintenance
The device uses lithium-polymer batteries that charge in approximately 2 hours. Charge the batteries when the LED indicator flashes red, the LCD shows only one bar, or the device fails to turn on. Ensure charging ports are sealed with rubber caps after charging. Store the device at room temperature and charge it fully before long-term storage.
Troubleshooting
If the dog does not respond, ensure the receiver is on and the contact points are touching the skin. If the range is insufficient, avoid touching the antenna and keep the transmitter vertical. For persistent issues, contact Dogtra support at [email protected] or +33 (0)1 30 62 65 65.
Manufacturer information
Dogtra
Practical help
Common problems
Dog does not respond to stimulation.
Ensure the receiver is turned on, the collar is tight enough for contact points to touch the skin, and the stimulation level is high enough.
Insufficient range or signal drop.
Do not touch the antenna while using the transmitter. Keep the transmitter vertical and away from obstacles like trees or metal structures.
Device does not hold a charge.
Clean the charging port with a cotton swab and rubbing alcohol. If the device is over two years old, the battery may need replacement.
Before use
- Charge the device fully before first use.
- Ensure the receiver is turned on.
- Check that the collar is fitted correctly (one finger space between strap and skin).
- Test the stimulation level on your hand before using it on the dog.
- Verify that the charging port rubber caps are securely closed.
Specs in practice
- Stimulation Level (0-127)
- Adjustable intensity of the electrostatic pulse; start at 0 and increase slowly.
Images and diagrams
- The transmitter has a rheostat dial for intensity and side buttons for pulse modes.
- The receiver collar has contact points that must touch the dog's skin.
- The test light tool is used to verify that the receiver is emitting a pulse.
Model compatibility
- The ARC 1200S is designed for dog training only.
- Not intended for use on humans or other living beings.
- Consult a doctor if you use an electronic medical device.
