Hobbywing QUICRUN Outer 1621SL Sensorless Brushless Motor
Quick guide for the Hobbywing QUICRUN Outer 1621SL brushless motor. Learn about installation, wiring, gearing, and temperature safety limits for your 1/24 scale RC crawler.
Table of contents
Manual images
Click an image to enlargeImportant Safety Information
Before using the Hobbywing QUICRUN Outer 1621SL motor, ensure all components in your build are compatible. Never apply full throttle without a pinion installed, as high RPMs without load can damage the motor. Stop usage immediately if the motor temperature exceeds 100°C (212°F) to prevent magnet demagnetization and coil damage.
Specifications
- Model: QUICRUN Outer 1621SL
- KV Rating: 3500KV
- Lipo Cells: 2-3S
- Weight: 16.7g
- Dimensions: Diameter 15.8mm, Length 21mm
- Shaft: 2.0mm diameter, 9mm length
- Poles: 12
- Application: 1/24 Crawler
Installation and Connection
The motor features 6 mounting holes with M2 specifications and a depth of 1.8mm. Ensure your mounting screws are not too long to avoid damaging the internal components. There are three mounting hole spacing options: 9mm, 10mm, and 12.5mm.
Wiring: There is no specific wire sequence required for the connection between the motor and the ESC. You can connect the three wires (A, B, C) in any order. If the motor rotates in the opposite direction, simply swap any two wires or adjust the "Motor Rotation" parameter in your ESC settings.
Gearing and Temperature Management
Selecting the correct gear ratio is critical for performance and longevity. Start with a small pinion (high FDR) and monitor the motor temperature regularly. If the temperature remains low, you may switch to a larger pinion (lower FDR). Always check the motor and ESC temperature after running, especially when changing track conditions or weather.
Manufacturer information
Hobbywing
Practical help
Common problems
Motor overheating
Check gear ratio; use a smaller pinion/higher FDR. Ensure temperature stays below 100°C/212°F.
Motor rotates in wrong direction
Swap any two of the three motor-to-ESC wires or change the 'Motor Rotation' setting in the ESC.
Before use
- Verify screw length (1.8mm depth max) to avoid internal damage.
- Ensure all electrical connections are secure.
- Check that the pinion is installed before applying throttle.
- Confirm the gear ratio is appropriate for the vehicle.
Specs in practice
- No-load Current
- Current draw when the motor is spinning without a load (0.6A).
Images and diagrams
- The wiring diagram illustrates the connection between the Battery, ESC, Receiver, and the Brushless Motor.
- The dimension diagram details the mounting hole spacing (9mm, 10mm, 12.5mm) and shaft dimensions.
Model compatibility
- Designed specifically for 1/24 scale crawlers.
- Compatible with 2S to 3S LiPo batteries.
