User Manual for HOTO 20V Pressure Washer Pro
Quick guide for the HOTO 20V Pressure Washer Pro (QWXCJ002). Learn how to assemble, operate, clean, and troubleshoot your pressure washer effectively.
Quick answers from the manual
Quick answer
- The HOTO 20V Pressure Washer Pro is a portable cleaning device. It features multiple water modes, a 20V battery, and supports self-priming or faucet water supply. p. 1
Key actions
- Assemble the spray lance and soap holder by aligning marks and rotating. p. 1
- Charge the battery using the USB-C port. p. 1
First start
- Install the battery pack, connect the water hose with the filter, and select the desired water mode. p. 1
Problems and fixes
Self-priming function does not work
Lower washer below water surface (max 1.5m), check hose connections, clean filter.
p. 1Maintenance and reset
- Clean the water inlet filter by removing the lower part of the filter head. p. 1
Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| Rated Pressure | 18 ± 2 Bar | Pressure for Jet mode | p. 1 |
| Battery Capacity | 2500 mAh | Battery capacity | p. 1 |
Where to find it in the PDF
- Product Overview and Instructions p. 1
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
The HOTO 20V Pressure Washer Pro is a portable, battery-operated cleaning device. This manual provides instructions for assembly, operation, and maintenance. Always ensure the battery is charged and the water inlet filter is clean before use. The device supports both self-priming (from a bucket) and faucet water supply.
Product Overview
The device consists of the following main components:
- Multi-Function Nozzle
- Spray Lance
- Soap Holder
- Handle
- Trigger
- Battery Pack
- Water Inlet Filter
Assembly and Disassembly
Spray Lance: Align the reducer of the spray lance with the slot inside the handle. Rotate the gun 90 degrees in the arrow direction to lock it. To disassemble, press and push the spray lance backward, then rotate 90 degrees and draw it out.
Soap Holder: Align the soap holder with the slot in the spray lance and rotate about 45 degrees to lock. Reverse the process to disassemble.
Battery Pack: Align the "●" mark on the handle with the "●" mark on the battery pack. Rotate 90 degrees until it locks. To remove, rotate 90 degrees in the opposite direction and pull downward.
Operating Instructions
Water Modes: Rotate the shell of the multifunctional nozzle to align the arrow with the desired mark. Five water types are available:
- Jet mode: For rinsing stubborn stains.
- 20-degree/40-degree water mode: For routine cleaning (cars, bicycles, windows).
- Foam/Shower mode: For spraying foam (with soap) or showering (without soap).
- Tilted mode: For cleaning higher planes like the top of a car.
Battery Charging: Remove the waterproof cover on the battery pack. Connect the USB-C charger to the battery pack. The battery level can be checked by pressing the display button.
Care and Maintenance
Cleaning the Water Inlet Filter: Rotate the water inlet filter head to remove the lower part, take out the filter, clean it, and reassemble.
Storage: Drain the machine and water pipe before storage. Wipe the body with a soft cloth. Keep in a safe, dry place away from frost and children.
Troubleshooting
If the washer does not start, check if the battery is properly installed or depleted. If the self-priming function fails, ensure the washer is not higher than 1.5m above the water surface, check for hose leaks, and ensure the inlet filter is clean and submerged.
Manufacturer information
Shanghai HOTO Technology Co., Ltd.
Practical help
Common problems
Washer starts but self-priming fails or pressure is low
Lower the washer to 1.5m below the water surface, check hose connections, clean the water inlet filter, and ensure the hose is not bent.
No soap sprays out in foam mode
Refill the soap holder.
Washer does not start
Reinstall the battery pack or charge the battery.
Washer automatically stops
Battery is depleted (charge it) or overheated (wait for it to cool down).
Before use
- Check for visible damage or leakage on the washer and components.
- Ensure the battery pack is fully charged.
- Connect the water inlet filter.
- Ensure the hose is not bent or twisted.
- If using foam mode, ensure the soap holder is filled.
Specs in practice
- Rated Pressure
- 18 ± 2 Bar (Jet mode) / 3 ± 3 Bar (Foam/Shower mode).
- Max Inlet Pressure
- 0.7 MPa.
Images and diagrams
- Assembly of the spray lance and soap holder.
- Battery pack installation and removal.
- Water inlet filter cleaning procedure.
- Water mode selection via the nozzle.
Model compatibility
- Self-priming mode: Washer absorbs water through a hose.
- Water-supplying mode: Requires faucet connection (accessories sold separately).
