User Manual for Philips 191V2 LCD Monitor
Quick guide for the Philips 191V2 LCD monitor. Includes installation steps, OSD menu navigation, SmartControl Lite software setup, troubleshooting, and technical specifications.
Quick answers from the manual
Quick answer
- The Philips 191V2 is an 18.5-inch LCD monitor. Installation involves attaching the base stand and connecting the power and signal cables (VGA/DVI). Use the OSD menu for adjustments. p. 6, 7
Key actions
- Install base stand p. 6
- Connect to PC p. 6
- Adjust OSD settings p. 7
First start
- Connect power and signal cables, then turn on the monitor and PC. p. 6
Show 4 more answers Show less
Problems and fixes
No picture
Check power and signal cable connections.
p. 35Maintenance and reset
- Use the 'Reset' option in the OSD menu to recall factory settings. p. 38
Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| Resolution | 1366x768 @ 60Hz | Native resolution | p. 19 |
Where to find it in the PDF
- Installation p. 6
- OSD Menu p. 7
- Technical Specifications p. 19
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
This guide provides essential information for setting up and using your Philips 191V2 LCD monitor. For optimal performance, ensure your PC is set to the native resolution of 1366x768 at 60Hz. Always use the provided power cord and ensure the power outlet is easily accessible.
Installation
To install the monitor:
- Base Stand: Place the monitor face down on a smooth surface. Firmly insert the base stand into the base column until it clicks.
- Connections: Connect the power cord to the back of the monitor. Connect the signal cable (VGA or DVI-D) to the video connector on your computer.
- Powering on: Plug the power cords into a nearby outlet and turn on both your computer and the monitor.
Operating the monitor
The monitor features an On-Screen Display (OSD) menu for adjusting settings:
- Control Keys: Use the buttons on the front bezel to navigate the OSD menu and confirm selections with the OK button.
- OSD Menu: Allows adjustments for Input, Picture (Brightness, Contrast, Color Temp), Language, OSD Settings, and Setup.
- Auto Adjustment: The 'AUTO' button automatically adjusts horizontal/vertical position, phase, and clock settings (valid in VGA mode only).
SmartControl Lite
SmartControl Lite is software that allows you to control your monitor via an on-screen graphic interface. It assists with fine-tuning resolution, color calibration, and other adjustments. The software launches automatically after installation or via the desktop shortcut.
Troubleshooting
If you encounter issues:
- No Picture: Ensure the power cord is connected and the power button is in the ON position. Check that the signal cable is securely connected.
- Image not centered: Use the 'Auto' function in the OSD menu or adjust Phase/Clock settings.
- No sound: Check audio cable connections and ensure the OSD 'Mute' setting is set to 'Off'.
Technical Specifications
The monitor features an 18.5-inch LCD panel with a native resolution of 1366x768 at 60Hz. It supports VESA mounting (100mm x 100mm) and includes DVI-D and VGA inputs.
Safety and Maintenance
- Keep the monitor away from direct sunlight, stoves, or heat sources.
- Do not block ventilation holes.
- Clean the screen with a soft, dry cloth. Never use organic solvents like alcohol or ammonia-based liquids.
- If the monitor gets wet, wipe it dry immediately.
Manufacturer information
Philips
Practical help
Common problems
No Picture (Power LED not lit)
Ensure the power cord is plugged into the outlet and the back of the monitor. Check that the power button is in the ON position.
No Picture (Power LED is Green)
Ensure the computer is on and the signal cable is properly connected. Check for bent pins on the cable.
Image is not centered
Use the 'Auto' function in the OSD menu or adjust Phase/Clock settings (VGA mode only).
No sound
Check audio cable connections and ensure the OSD 'Mute' setting is set to 'Off'.
Before use
- Ensure the power plug and outlet are easily accessible.
- Place the monitor on a smooth surface to avoid scratching the screen during assembly.
- Verify the signal cable is securely connected to the PC.
- Set the PC display resolution to 1366x768 @ 60Hz.
Show more Show less
Specs in practice
- Native Resolution
- 1366x768 @ 60Hz for optimal performance.
- Power Consumption
- < 16.6W (typical) in normal operation.
Images and diagrams
- Base stand assembly involves inserting the stand into the base column.
- Rear ports include AC power input, VGA input, DVI-D input, and Kensington lock.
Model compatibility
- Compatible with Windows 7/Vista/XP, Mac OSX, and Linux.
- Supports DVI-D (digital, HDCP) and VGA (analog) inputs.
