Installation Instructions for Resistex Saline Lighting Fixture
A comprehensive installation guide for the Resistex Saline lighting fixture. Includes safety precautions, step-by-step mounting instructions, and maintenance tips.
Quick answers from the manual
Quick answer
- The Resistex Saline is a lighting fixture that must be installed by a professional. Ensure power is off before installation and handle with ESD precautions. p. 1
Key actions
- Turn off power before starting installation. p. 2
- Connect electrical wires to the terminal block. p. 2
Maintenance and reset
- Clean only with non-abrasive, non-chemical products. p. 1
Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| IP Rating | IP55 | Dust and water protection | p. 1 |
| Impact Protection | IK10 | Mechanical impact resistance | p. 1 |
Where to find it in the PDF
- Safety and Maintenance p. 1
- Installation Steps p. 2
Table of contents
Quick guide from the manual
The Resistex Saline is a lighting fixture that requires professional installation. Ensure the power is disconnected before starting any work. The installation involves mounting the base, connecting the electrical wiring, and securing the fixture body. Handle the device with care due to the risk of electrostatic discharge (ESD).
Safety notes
- Electrical Safety: Never work on the luminaire while it is connected to a power source.
- Professional Installation: The installation must be performed by a qualified professional in compliance with local electrical standards and regulations.
- ESD Protection: The device is sensitive to electrostatic discharges. Handle with necessary precautions.
Installation
Follow these steps to install the fixture:
- Preparation: Ensure the power supply is turned off (OFF).
- Base Mounting: Prepare the mounting surface according to the dimensions provided (101mm spacing). Drill holes (Ø8mm) and insert anchors.
- Wiring: Feed the electrical cables through the base.
- Electrical Connection: Connect the wires to the terminal block as indicated in the diagram (ON/OFF).
- Securing: Fix the base to the ground using the provided hardware.
- Final Assembly: Attach the main body of the fixture to the base and secure it with the provided screws.
Maintenance
- Do not use chemicals or abrasive products to clean the fixture.
- Keep these instructions for future dismantling or maintenance.
Practical help
Common problems
Electrostatic discharge risk
Handle the luminaire with necessary precautions during installation.
Cleaning the fixture
Do not use chemicals or abrasive products; wipe with a soft cloth.
Before use
- Ensure the power supply is completely disconnected.
- Verify that the installation is performed by a professional installer.
- Check that the mounting surface is suitable for the fixture dimensions.
- Ensure you have the necessary tools (drill, screwdriver, wrench).
Images and diagrams
- The installation diagram shows an 11-step process.
- Steps 1-3 cover preparation and drilling.
- Steps 4-9 cover electrical connection and base mounting.
- Steps 10-11 cover final assembly.
