Sealey PDM Series 16-Speed Premier Floor Pillar Drills

Product Overview

The Sealey PDM series comprises professional floor-mounted pillar drills designed for heavy-duty workshop use. These models feature robust aluminium-bodied induction motors, no-volt release switches for safety, and microswitch-protected pulley covers. Selected models include integrated work lights and precision rack-and-pinion table height adjustment.

Safety Instructions

Always disconnect the drill from the power supply before performing maintenance or changing accessories. Ensure all guards are in place and functional. Operators must wear appropriate eye and ear protection. Do not operate the drill if you are tired, under the influence of substances, or if the machine is damaged. Ensure the drill is securely bolted to the floor and the workpiece is clamped firmly; never hold the workpiece by hand.

Assembly and Setup

The drill must be assembled by securing the column to the base, installing the table bracket with the rack, and mounting the head assembly. The chuck is installed by seating the arbor tapers into the spindle. Ensure the safety guard is correctly positioned and the microswitches are engaged.

Operation

Before starting, ensure the drill is unplugged. Insert the drill bit into the chuck and tighten securely. Adjust the table height and tilt as required for the specific task. Speed adjustments are made by opening the pulley case and repositioning the belts according to the speed chart. Always use a piece of wood under the workpiece to prevent damage to the table when the drill bit breaks through.

Maintenance and Troubleshooting

Regular maintenance includes cleaning the tool after each use, blowing out dust from the motor, and lubricating the rack, gear, and spindle sleeve. If the machine fails to start, check that the chuck guard is deployed and the belt cover is secure. For issues like excessive noise or drill wobble, inspect belt tension, spindle lubrication, and chuck security. Dispose of the product at the end of its life in accordance with WEEE regulations.
