Sloan 115-1.28-CP-2-OFST Manual Flushometer
Quick guide for the Sloan 115-1.28-CP-2-OFST manual flushometer. Includes technical specifications, operating pressure requirements, and rough-in installation dimensions.
Table of contents
Manual images
Click an image to enlargeQuick Guide
The Sloan 115-1.28-CP-2-OFST is a manual water closet flushometer designed for efficiency and durability. Before installation, ensure your water supply pressure is within the required range of 15-80 psi (103-552 kPa). This unit is designed for fixtures with a top spud connection and requires a 1-inch supply pipe.
Product Overview
This flushometer features a dual-filtered fixed bypass diaphragm and a polished chrome finish. It is engineered for water conservation, utilizing CID technology to control flush accuracy and a non-hold open handle to prevent excessive water usage.
Technical Specifications
- Flush Volume: 1.28 gpf (4.8 lpf)
- Valve Type: Diaphragm
- Valve Body Material: Semi-red Brass
- Fixture Type: Water Closet
- Fixture Connection: Top Spud
- Supply Pipe: 1 inch (25mm)
- Spud Coupling: 1.5 inch (38mm)
- Offset: 2 inches (51mm)
- Operating Pressure: 15-80 psi (103-552 kPa)
Installation Rough-in
The installation requires specific clearance and positioning. The rough-in dimension is 24 inches (610mm) from the center of the waste to the supply line. Ensure a minimum of 2-1/4 inches (57mm) clearance from the wall. The supply line connection is 1 inch I.P.S.
Features and Compliance
The unit is built for longevity with dezincification-resistant brass castings and a high chloramine-resistant PERMEX synthetic rubber diaphragm. It is ADA compliant and meets various certifications, including cUPC Green Certified, IAPMO, and EPA WaterSense listing when used with a compatible 1.28 gpf fixture.
Practical help
Before use
- Verify water supply pressure is between 15-80 psi (103-552 kPa).
- Ensure the fixture is a compatible water closet with a top spud connection.
- Confirm the 24-inch rough-in dimension matches your installation site.
- Check that the supply pipe is 1 inch (25mm).
- Ensure the installation area allows for the 2-inch offset.
Specs in practice
- 1.28 gpf (4.8 lpf)
- Gallons per flush; indicates the water volume used per cycle.
- 2-inch Offset
- The distance the flushometer pipe is offset from the center line.
Images and diagrams
- The rough-in drawing shows the 24-inch distance from the center of the waste to the supply line.
- The diagram indicates a 1-inch I.P.S. supply connection.
- The drawing illustrates the 2-1/4 inch minimum clearance required from the wall.
Model compatibility
- Requires a compatible water closet fixture.
- WaterSense compliant only when used with a 1.28 gpf (4.8 lpf) WaterSense fixture.
