Installation Manual for The Home Depot 21036-W2GD Chandelier
Quick installation guide for The Home Depot 21036-W2GD chandelier. Includes wiring diagram, parts list, and essential safety precautions for proper setup.
Quick answers from the manual
Quick answer
- This manual provides installation steps and a wiring diagram for the 21036-W2GD chandelier. It emphasizes turning off the power at the main circuit breaker before starting. p. 2
Key actions
- Turn off power at the main circuit breaker. p. 2
- Connect wires using the provided wire nuts. p. 2
Where to find it in the PDF
- Installation Instructions p. 2
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
This document provides the necessary steps to install the 21036-W2GD chandelier. Before beginning, ensure the power supply is turned off at the main circuit breaker. If you have questions or encounter issues, you can contact support at [email protected].
Safety Warnings
- Electrical Safety: Always turn off the electricity at the main circuit breaker before starting installation.
- Professional Installation: It is highly recommended to have a qualified electrician install this light.
- Compliance: Follow N.E.C. requirements. If using special control devices, follow their specific instructions.
- Handling: All glass components are fragile; handle with care.
- Proposition 65: This product contains lead, a chemical known to the state of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling.
Parts Included
- Junction box (A)
- Wire nuts (B)
- Mounting brackets (C)
- Studs (D)
- Leading wires (E)
- Wires (F)
- Screws (G)
- Canopy (J)
Installation and Wiring
Follow the assembly steps provided in the diagram:
- Connect the mounting bracket (C) and studs (D) to the junction box (A).
- Connect the leading wires (E) and fixture wires (F) using the wire nuts (B).
- Secure the canopy (J) and screws (G) to the mounting bracket (C).
Ensure all wiring connections are secure and meet safety standards as shown in the provided wiring connection diagram.
