User Manual for Trevi HMP 12E20 Wireless Earphones
Quick guide for the Trevi HMP 12E20 wireless earphones. Learn how to pair, control music playback, manage phone calls, and charge your device.
Table of contents
Quick Guide
The Trevi HMP 12E20 are wireless earphones designed for sports and daily use. This guide provides essential instructions for pairing, operation, and maintenance. Ensure the charging case is fully charged before the first use.
Package Contents
- Charging case
- Earphones
- USB Type-C cable
Turning On/Off
Automatic: The earphones turn on automatically when removed from the charging case and turn off when placed back inside.
Manual: Press and hold the touch control (5) for 2 seconds to turn on. Press and hold for 3 seconds to turn off.
Bluetooth Pairing
- Remove both earphones from the charging case. They will pair with each other automatically.
- Turn on Bluetooth on your smartphone and search for the device named "HMP 12E20".
- Select the device to complete the pairing.
Music Playback Controls
- Play/Pause: Tap the touch switch (5) once.
- Volume Up: Tap the right earphone touch switch twice.
- Volume Down: Tap the left earphone touch switch twice.
- Next Track: Tap the right earphone touch switch three times.
- Previous Track: Tap the left earphone touch switch three times.
Phone Call Management
- Answer Call: Tap the touch switch (5) once.
- Reject Call: Press and hold the touch switch (5) for 2 seconds.
- End Call: Tap the touch switch (5) once.
Charging
Charging the Case: Connect the provided USB Type-C cable to the charging port on the case and a power source. The LED indicator (4) will flash during charging and remain lit when fully charged.
Charging the Earphones: Place the earphones into the charging case. They will start charging automatically. The LED indicator on the case will light up.
Technical Specifications
- Bluetooth Version: 5.0
- Battery (Case): Rechargeable Li-Poly 300mAh
- Battery (Earphones): Rechargeable Li-Poly 30mAh
- Charging Port: USB Type-C
Manufacturer information
TREVI S.p.A.
Practical help
Common problems
Earphones fail to pair with each other.
Place both earphones back into the charging case and remove them again to reset the automatic pairing process.
Bluetooth connection drops.
Ensure the distance between the earphones and the smartphone is within 10 meters and there are no significant obstacles.
Before use
- Charge the charging case fully before the first use.
- Ensure Bluetooth is enabled on your smartphone.
- Remove any protective film from the charging contacts on the earphones.
- Keep the earphones within 1 meter of the smartphone during the initial pairing process.
Specs in practice
- Bluetooth 5.0
- Provides a stable wireless connection with compatible devices.
- 300mAh Case Battery
- Provides multiple recharges for the earphones on the go.
Images and diagrams
- The touch switch (5) is located on the outer surface of each earphone.
- The LED indicator (4) on the case provides status updates on charging progress.
Model compatibility
- Compatible with most Bluetooth-enabled smartphones, tablets, and computers.
