User Manual for Vevor 1.5-Ton Low Profile Floor Jack VL-80020
Quick guide for the Vevor 1.5-Ton Low Profile Floor Jack (Model VL-80020). Includes technical specifications, dimensions, and usage overview.
Table of contents
Quick guide from the manual
This document provides the technical specifications and dimensions for the Vevor 1.5-Ton Low Profile Floor Jack (Model VL-80020). This tool is designed for lifting vehicles within its rated capacity. Always ensure the jack is used on a flat, stable surface and that the vehicle is properly secured before attempting to lift.
Product Overview
The Vevor 1.5-Ton Low Profile Floor Jack is a hydraulic lifting device engineered for vehicles with low ground clearance. It features a compact design for easy storage and maneuverability.
Technical Specifications
The following dimensions are provided for the VL-80020 model:
- Capacity: 1.5 Tons
- Total Length: 16.54 in / 420 mm
- Total Width: 7.48 in / 190 mm
- Height: 5.12 in / 130 mm
- Handle Length: 14.6 in / 370 mm
Safety and Usage
Warning: Never exceed the rated capacity of 1.5 tons. Failure to follow safety instructions can result in serious injury or damage to the vehicle.
- Always use jack stands to support the vehicle after lifting; never rely solely on the floor jack.
- Ensure the saddle is centered under the vehicle's designated lift point.
- Operate the jack on a hard, level surface.
- Keep hands and feet clear of the lifting mechanism during operation.
Manufacturer information
VEVOR
Practical help
Common problems
Jack fails to lift the load
Ensure the release valve is fully closed by turning the handle clockwise. Check for sufficient hydraulic oil levels.
Load slips or jack lowers unexpectedly
Ensure the saddle is properly positioned on the vehicle's lift point and the jack is on a level surface.
Before use
- Verify the vehicle weight does not exceed 1.5 tons.
- Inspect the jack for any visible damage, leaks, or loose parts.
- Ensure the vehicle is parked on a flat, level surface.
- Locate the vehicle manufacturer's recommended lift points.
- Ensure the release valve is closed before attempting to pump.
Specs in practice
- 1.5 Ton Capacity
- The maximum weight the jack is rated to lift safely.
Images and diagrams
- The diagram illustrates the physical dimensions of the jack, including the length (16.54 in), width (7.48 in), and height (5.12 in).
- The handle length is specified as 14.6 in.
Model compatibility
- Designed for general automotive use within the 1.5-ton weight limit.
- Suitable for low-clearance vehicles.
