Installation Guide for Crystorama 2443-OP-BN Three Light Bathroom Vanity
Step-by-step installation instructions for the Crystorama 2443-OP-BN three-light bathroom vanity fixture. Includes parts list, bulb requirements, and safety warnings.
Quick answers from the manual
Quick answer
- The Crystorama 2443-OP-BN is a three-light bathroom vanity fixture. It requires 3 Medium Base bulbs (60W recommended, 100W max) and must be installed by a licensed electrician. p. 1
Key actions
- Install the mounting plate to the outlet box p. 1
- Secure the backplate to the mounting plate p. 1
- Attach the glass shade and secure with the socket ring p. 1
Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| Bulb Type | Medium Base | Standard bulb socket | p. 1 |
| Recommended Wattage | 60W | Recommended per bulb | p. 1 |
| Maximum Wattage | 100W | Maximum per bulb | p. 1 |
| Rating | Damp rated | Suitable for bathroom use | p. 1 |
Show 1 more answers Show less
Where to find it in the PDF
- Installation and Specifications p. 1
- Parts List and Exploded View p. 2
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
This document provides instructions for the assembly and installation of the Crystorama 2443-OP-BN three-light bathroom vanity fixture. The fixture is damp-rated, making it suitable for bathroom environments. Installation should be performed by a licensed electrician in accordance with the National Electric Code.
Safety and Warnings
- Electrical Danger: Always turn off the power at the circuit breaker before beginning installation.
- Professional Installation: All electrical components must be installed by a licensed electrician.
- Lead Warning: This product can expose you to lead, which is known to the state of California to cause cancer and/or birth defects or reproductive harm.
Installation Steps
- Mounting: Install the mounting plate to the outlet box using two outlet box screws.
- Backplate: Install the backplate onto the mounting plate and secure it with the provided screws.
- Shade: Install the glass shade over the socket and secure it using the socket ring.
- Bulb: Install the bulb (not included) into the socket.
Parts List
- Mounting hardware
- Mounting plate
- Backplate (L4-7/8" x W4-7/8" x D1-3/8")
- Screws
- Socket
- Glass shade (#XRF2441SHA6IN)
- Socket ring
Technical Specifications
The fixture requires 3 Medium Base bulbs. It is recommended to use 60W bulbs, with a maximum capacity of 100W per bulb. LED bulbs are recommended for extended use.
Manufacturer information
Crystorama
Practical help
Common problems
Fixture does not light up
Ensure the bulb is securely installed and the power is turned on at the circuit breaker.
Glass shade is loose
Ensure the socket ring is tightened securely over the glass shade.
Before use
- Turn off main power at the circuit breaker
- Verify you have 3 Medium Base bulbs
- Ensure the outlet box is compatible
- Hire a licensed electrician for installation
Show more Show less
Specs in practice
- 60W Recommended
- Optimal wattage for standard usage.
Images and diagrams
- The exploded view shows the assembly order: Mounting plate -> Backplate -> Socket -> Glass Shade -> Socket Ring.
Model compatibility
- Fixture is Damp rated.
