User Manual for Dometic 2 Cook Turbo FFD 203F2 Gas Stove
Quick guide for the Dometic 2 Cook Turbo FFD 203F2 gas stove. Includes setup, lighting instructions, GreenGrill cooking tips, maintenance, and troubleshooting.
Quick answers from the manual
Quick answer
- The Dometic 2 Cook Turbo FFD is a portable gas stove. Ensure it is used in a well-ventilated area, connected to an approved gas cylinder with a compatible regulator, and placed on a firm, level surface. p. 14, 15
Key actions
- Connect gas supply p. 13, 15
- Light the burner p. 14, 16
First start
- Remove all packaging, check for gas leaks, and ensure the appliance is on a stable surface. p. 14, 15
Show 3 more answers Show less
Problems and fixes
Blocked jet
Remove cooking surfaces, unscrew bottom panel, lift airvent cover, remove jet with spanner, replace with new jet.
p. 17Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| Heat Input | 4.4kW total | 2.2kW per burner | p. 13 |
Where to find it in the PDF
- Safety Information p. 14
- Assembly and Use p. 14, 15
- Maintenance and Troubleshooting p. 17
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
The Dometic 2 Cook Turbo FFD (Model 203F2) is a portable gas stove designed for both indoor and outdoor use. Before use, ensure the appliance is placed on a firm, level surface and that all protective packaging has been removed. Proper ventilation is critical for safe operation.
Assembly and gas connection
Ensure the appliance is connected to an approved gas cylinder using a compatible hose and low-pressure regulator. Check all connections for leaks using soapy water before lighting. Do not use the appliance if the hose is damaged or worn. The gas cylinder must not exceed 500mm in height and 400mm in width.
Operating the appliance
To light the burner using the piezo igniter: push in and turn the control knob 90 degrees anti-clockwise, then press the piezo button. If it does not ignite within 2-3 seconds, turn the knob back to the OFF position and wait at least 1 minute before trying again. For cold starts, you may also use a BBQ lighter inserted through the vent holes under the burner.
GreenGrill cooking
Most cooking surfaces feature a GreenGrill ceramic coating. We recommend seasoning the surface before first use by rubbing it with cooking oil and heating on medium for 2-3 minutes. Use only silicone or wooden utensils to avoid damaging the coating. Clean surfaces only after they have cooled completely.
Maintenance and troubleshooting
Clean the appliance after every use. Do not immerse the stove body in water. If the flame is weak or absent, the jet may be blocked. To replace a blocked jet: remove cooking surfaces, unscrew the bottom panel, lift the airvent cover, and remove the jet using a suitable spanner. Do not attempt to clean the jet with a pin or other sharp object.
Manufacturer information
Dometic
Practical help
Common problems
Yellowish flame or no flame
The jet may be blocked. Remove and clean or replace the jet.
Gas leak smell
Turn off the gas supply immediately at the cylinder and the appliance. Move to a flame-free area and check connections with soapy water.
Flare-ups when cooking fatty meat
Reduce the heat setting until the flaring ceases.
Before use
- Check hose and regulator for wear or damage
- Ensure appliance is on a firm, level surface
- Check for gas leaks using soapy water
- Ensure adequate ventilation
- Remove all protective packaging and plastic
- Inspect for insects or webs in the burner area
Show more Show less
Specs in practice
- Gas Pressure
- Must match local supply (28-50mbar depending on region).
Images and diagrams
- Page 7: Exploded view of components
- Page 8: Safety distances and gas connection
- Page 9: Quick release and adapter systems
- Page 10: Jet replacement steps
Model compatibility
- Requires approved hose and regulator
- Not for use with reticulated gas supply
- Use only with gas cylinders max 500mm height and 400mm width
