User Manual for Eco-Worthy 5W/10W Solar Trickle Charger
Quick guide for the Eco-Worthy 5W and 10W Solar Trickle Charger. Includes installation steps, wiring instructions for cigarette lighter and alligator clips, safety precautions, and technical specifications.
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
This solar charger is designed to maintain 12V batteries in vehicles like cars, trucks, boats, and RVs. It prevents battery drain using solar energy and features a built-in diode to prevent reverse charging.
Safety Information
Read all instructions before use. Do not modify the product. Use only for intended purposes. The warnings in this manual do not cover every possible scenario; use common sense and remain aware of your surroundings.
Features
- Built-in diode prevents reverse charging
- SAE quick connector for plug and play
- Waterproof and UV-resistant fiberglass
- 4 PVC suckers for easy mounting
- Includes interchangeable clamps and cigarette lighter cables
Product List
- Solar panel
- Alligator clip to SAE connector cable
- Cigarette lighter plug to SAE connector cable
- 4 PVC suckers
Specifications
5W Model: 18.7V Vmp, 0.29A Imp, 14.5V Over-charged Protection Voltage.
10W Model: 18.7V Vmp, 0.58A Imp, 14.5V Over-charged Protection Voltage.
Installation
Use the 4 included PVC suckers to attach the panel to the inside of the windshield or the exterior of the vehicle.
Wiring Connections
Cigarette Lighter Connection
Connect the cigarette lighter cable to the solar panel's SAE plug. Insert the connector into the vehicle's cigarette lighter socket. Note: This works with the majority of vehicles, but some sockets are disabled when the engine is off.
Alligator Clips Connection
Connect the alligator clip cable to the solar panel's SAE plug. Clamp the red clip to the positive (+) terminal and the black clip to the negative (-) terminal of the battery.
Safety Precautions
- Remove the cigarette lighter plug before starting the motor. Do not use while driving.
- Do not short circuit the terminals or connect in reverse.
- Indicator Light: Always on = charging; Flashing = battery full; Off = no solar input.
- Remove protective wrapping before use.
- Avoid scratching the surface and do not subject the panel to uneven pressure.
Manufacturer information
ECO-WORTHY
Practical help
Common problems
Cigarette lighter socket doesn't work
Some vehicles turn off the socket when the engine is off. Use the alligator clips to connect directly to the battery instead.
Indicator light is off
There is no solar input. Ensure the panel is exposed to direct sunlight.
Indicator light is flashing
The battery is fully charged.
Before use
- Remove protective wrapping from the solar panel
- Ensure the battery is a 12V battery
- Check that the cigarette lighter socket is active (if using that method)
- Verify the red clip is positive (+) and black is negative (-)
Specs in practice
- Vmp (Optimum Operating Voltage)
- The voltage at which the solar panel produces maximum power (18.7V).
- Imp (Optimum Operating Current)
- The current at which the solar panel produces maximum power (0.29A for 5W, 0.58A for 10W).
Images and diagrams
- The panel uses an SAE connector for quick swapping between the cigarette lighter adapter and alligator clips.
Model compatibility
- Designed for 12V batteries.
- Not for use while driving; remove the plug before starting the motor.
