Furrion FCR10DCDTA 10 Cu. Ft. 12V Built-in Refrigerator
Quick guide for the Furrion FCR10DCDTA 12V built-in refrigerator. Includes specifications, installation dimensions, and model variants.
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
This document provides essential specifications and installation dimensions for the Furrion FCR10DCDTA 12V built-in refrigerator. This appliance is designed for automotive and RV use. Please note that door panels and charcoal filters are sold separately.
Product overview
The Furrion 10 Cu. Ft. 12V refrigerator features a high-efficiency DC compressor and is designed for built-in installation. Key features include:
- Quiet operation: 43dB noise level.
- Storage: 10 cu. ft. total volume (2.8 cu. ft. freezer, 7.2 cu. ft. fridge).
- Convenience: Built-in door lock and half-gallon bottle holder.
- Flexibility: Reversible door and changeable door panels.
Specifications
Technical parameters for the FCR10DCDTA model:
- Rated Voltage: DC 12V.
- Noise Level: 43dB.
- Freezer Capacity: 2.8 cu. ft.
- Fridge Capacity: 7.2 cu. ft.
- Reversible Door: Yes.
Installation dimensions
Ensure your installation space meets the following requirements:
- Product Size (W x H x D): 24 1/4” x 60 3/16” x 25 3/4” (616 x 1528 x 654mm).
- Recessed Size (W x H x D): 52 11/16” x 23 5/16” x 23 3/4” (1338 x 592 x 604mm).
- Product Weight: 134 lbs / 61 kg.
Model variants
The FCR10DCDTA series is available in multiple configurations based on hinge side (Left/Right), exterior color (Black/Gray), and door panel finish (High Gloss Black, Matte Black, VCM Stainless Steel, Black VCM Stainless Steel). Please verify the specific part number when ordering.
Manufacturer information
Furrion
Practical help
Common problems
Door panel not included
The door panel is sold separately; ensure you purchase the correct panel for your specific model.
Charcoal filter missing
The charcoal filter (Part C-FCR10DCDTA-B01) is sold separately.
Before use
- Verify the power source is 12V DC.
- Ensure the installation space matches the recessed dimensions (52 11/16” x 23 5/16” x 23 3/4”).
- Check if the door hinge orientation (Left/Right) matches your installation needs.
- Confirm if you have purchased the required door panel separately.
Specs in practice
- Rated Voltage
- Requires a DC 12V power supply.
- Recessed Size
- The required cutout dimensions for built-in installation: 52 11/16” x 23 5/16” x 23 3/4”.
Model compatibility
- Door panels are sold separately.
- Charcoal filter is sold separately.
- Reversible door feature is available.
