User Manual for IKEA TILLREDA 2-Zones Portable Induction Hob
Quick guide and user manual for the IKEA TILLREDA 2-Zones Portable Induction Hob. Includes installation, safety instructions, daily operation, troubleshooting, and maintenance.
Quick answers from the manual
Quick answer
- The TILLREDA 2-Zones Portable Induction Hob is operated via touch sensor fields. It features 9 power levels, a child lock, and automatic safety shut-off. p. 9, 10
Key actions
- Activate/Deactivate Child Lock p. 10
- Turn ON/OFF p. 9
First start
- Plug into a standard socket. The child lock will be active; press and hold the Lock key for 3 seconds to deactivate. p. 9
Problems and fixes
E2
Cookware empty or too hot. Turn off, wait 5 mins, restart.
p. 13
E0
Internal exception. Turn off, wait 5 mins, restart.
p. 13Error codes
| Code | Meaning | Action | Pages |
|---|---|---|---|
| E2 | Cookware empty or too hot | Turn off, wait 5 mins, restart | p. 13 |
| E0 | Internal exception | Turn off, wait 5 mins, restart | p. 13 |
Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| Rated Power | 3200W | Total power | p. 14 |
| Rated Voltage | 220-240V~ | p. 14 |
Where to find it in the PDF
- Product Description p. 8
- Troubleshooting p. 13
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
The IKEA TILLREDA 2-Zones Portable Induction Hob is designed for domestic indoor use. It features two cooking zones with independent power controls, a child lock, and automatic safety shut-off features. Always ensure the appliance is placed on a flat, solid surface and that the cookware used is suitable for induction cooking.
Safety information
Important: Read all instructions before use. Do not leave the appliance unattended during operation. Keep children and pets away from the hob. Do not place metal objects like knives, forks, or spoons on the cooking surface as they can get hot. If the surface is cracked, switch off the appliance immediately to avoid electric shock.
Product description
The hob features two heating zones: a front zone (170mm, 2000W) and a rear zone (158mm, 1200W). The control panel includes an ON/OFF button, power level display, lock/child lock button, and power level adjustment (+/-) sensors.
Daily use
- Connecting: After plugging in, the child lock is activated. Press and hold the Lock key for 3 seconds to deactivate.
- ON/OFF: Press the ON/OFF key to enter standby mode. If no power level is selected within 30 seconds, the hob switches off automatically.
- Power levels: Use the - and + sensors to adjust power levels from 1 to 9.
- Lock function: Press the Lock key for 3 seconds to lock the control panel during operation or when the hob is off (Child Lock).
Cookware guidance
Only use pots and pans with a ferromagnetic base. Suitable materials include cast iron, enamelled steel, carbon steel, stainless steel, and aluminium with a ferromagnetic coating. The minimum base diameter for both cooking zones is 120mm.
Care and cleaning
Switch off the appliance and let it cool down before cleaning. Do not use steam cleaners or high-pressure cleaners. Use a scraper (not included) to remove sugar or plastic residues immediately. Clean the surface with a damp cloth and washing-up liquid after each use.
Troubleshooting
If the appliance stops operating, check the error codes displayed. Common issues include incorrect cookware, blocked air inlets, or power supply issues. Always turn off the appliance and wait 5 minutes before restarting if an error occurs.
Manufacturer information
IKEA
Practical help
Common problems
Appliance does not operate
Check power connection, ensure child lock is off, and touch only one sensor field at a time.
Error E2
Cookware is empty (dry-boiling) or temperature is too high. Turn off, wait 5 minutes, and restart.
Error E0
Internal exception. Turn off, wait 5 minutes, and restart. If it persists, contact IKEA.
Before use
- Remove all packaging, stickers, and film.
- Place the appliance on a flat, solid surface.
- Check that the power supply matches the rating plate.
- Verify cookware is suitable for induction (magnetic base).
- Ensure air inlets and outlets are not blocked.
Specs in practice
- Front Cooking Zone
- 170mm diameter, 2000W max power.
- Rear Cooking Zone
- 158mm diameter, 1200W max power.
Images and diagrams
- The control panel features touch sensors for On/Off, power level adjustment, and locking functions.
- The heating areas are clearly marked on the glass surface.
Model compatibility
- Only use ferromagnetic cookware (cast iron, enamelled steel, carbon steel, stainless steel, aluminium with ferromagnetic coating).
- Minimum cookware diameter is 120mm.
