User Manual for JBL STAGE 1220B Dual 12-Inch Subwoofer Enclosure
Get the most out of your JBL STAGE 1220B dual 12-inch subwoofer enclosure with this comprehensive user guide. Includes installation tips, wiring diagrams, technical specifications, and safety advice.
Table of contents
Manual images
Click an image to enlargeQuick Guide
The JBL STAGE 1220B is a dual 12-inch subwoofer enclosure designed for automotive audio systems. Before beginning installation, ensure you have the necessary tools and experience. If you are unsure, consult an authorized JBL car audio dealer for professional installation.
Safety Warnings:
- Always wear protective eyewear when using tools.
- Turn off all audio components and electrical devices before starting.
- Disconnect the negative (-) lead from your vehicle's battery.
- Be aware of brake lines, fuel lines, and wiring harnesses when drilling or cutting.
Installation and Mounting
Choose a mounting location that does not interfere with cargo, the fold-down rear seat, or the trunk lid. The best location is typically a corner of the trunk or cargo area. Secure the enclosure firmly to the mounting surface to prevent movement while driving.
Speaker Connections
Connect the positive (+) and negative (-) terminals on the enclosure to the corresponding outputs on your amplifier. Observe proper polarity to ensure optimal performance. Use at least 0.5mm² (20 AWG) speaker wire for these connections. Ensure all electrical connections are secure and properly insulated.
Technical Specifications
The JBL STAGE 1220B features the following specifications:
- Power Handling (RMS): 500 watts
- Power Handling (Peak): 1000 watts
- Sensitivity: 94dB
- Frequency Response: 34Hz – 200Hz
- Nominal Impedance: 2 ohms
- Voice Coil Diameter: 2 inches (50.8mm)
- Enclosure Materials: 5/8-inch MDF with black carpet covering
General Care
The loudspeaker enclosure may be cleaned with a damp cloth. Do not use any cleaners or solvents. This product is designed for mobile applications and is not intended for connection to mains power.
Manufacturer information
JBL
Practical help
Common problems
Distorted sound or poor performance
Check that the speaker wire polarity (+ to + and - to -) is correct at both the amplifier and the subwoofer terminals.
Hearing fatigue or damage
Avoid listening at high volumes for extended periods. Establish a safe, comfortable sound level by starting low and increasing slowly until clear without distortion.
Before use
- Disconnect the negative (-) battery terminal before starting installation.
- Ensure you have 0.5mm² (20 AWG) or thicker speaker wire.
- Check for clearance behind mounting surfaces to avoid puncturing lines.
- Wear protective eyewear when using tools.
- Secure the enclosure to the mounting surface.
Specs in practice
- Power Handling (RMS)
- 500W - The continuous power the subwoofer can handle safely.
- Power Handling (Peak)
- 1000W - The maximum short-term power the subwoofer can handle.
Images and diagrams
- The wiring diagram illustrates the connection from the Head Unit to the Amplifier, and then to the Subwoofer terminals, emphasizing the importance of correct polarity (+ to +, - to -).
Model compatibility
- Designed for mobile automotive applications.
- Not intended for connection to mains power.
