Infrared Group Urinal Flush Valve Sanela SLP 05KBX
Quick guide for the Sanela SLP 05KBX infrared group urinal flush valve. Learn about installation requirements, technical specifications, Bluetooth configuration, and sensor settings.
Table of contents
Quick guide from the manual
The Sanela SLP 05KBX is an infrared-controlled flush valve designed for group urinal flushing. It features Bluetooth connectivity for parameter adjustments via the Sanela Control app. The system detects users in front of the urinals and triggers a flush after all users have left the monitored zone. Key operational requirements include a reflective foil for the sensor and a stable water pressure between 0.15 and 0.6 MPa.
Characteristics
- Bluetooth Control: Parameter settings and communication via the Sanela Control app or SLD 03 remote.
- Group Flushing: Designed to flush multiple urinals simultaneously.
- Sensor Logic: Responds to presence in the sensor axis (approx. 200 mm from the front edge) for longer than 7.5 seconds.
- Automatic Flushing: Triggers 24 hours after the last valve activation to maintain hygiene.
- Adjustable Settings: Flush time is adjustable from 0.5 to 15.5 seconds.
- Battery Monitoring: Includes battery status tracking.
Technical Specification
- Dimensions (Stainless steel cover): 170 x 170 x 10 mm
- Dimensions (Plastic box): 140 x 140 x 75 mm
- Dimensions (Stainless steel box with valve): 145 x 155 x 100 mm
- Supply voltage: 6 V
- Power input: 3 W
- Sensor Range: 0.3 - 3 m (to reflective foil)
- Recommended working pressure: 0.15 - 0.6 MPa
- Flow rate: 70 l/min at 0.15 MPa
- Water inlet: External thread min. G 1 inch
- Water outlet: External thread G 1 inch
Building preparation
The installation requires specific preparation of the wall and plumbing. The system utilizes a plastic installation box for electronics and a stainless steel installation box for the valve. A reflective foil must be installed to ensure the sensor functions correctly. Ensure the water supply cross-section is at least 32 mm (PN 16).
Supply Specification
The SLP 05KBX package (Supply No. 01057) includes:
- Stainless steel cover with electronics (including Bluetooth module)
- Plastic installation box with electronics
- Stainless steel installation box with fittings and solenoid valve
- Stainless steel cover for the valve box
- Reflective foil
- 4 pcs AA alkaline batteries 1.5 V 2700 mAh
Recommended accessories
- SLD 03 (Supply No. 07030): Remote control for parameter adjustment.
- SLA 02 (Supply No. 06020): Inlet fitting with gasket for urinals with rear inlet.
- SLA 30 (Supply No. 06300): Reflective foil.
- SLA 36 (Supply No. 06360): Set of 4 AA alkaline batteries.
- Sanela Control App: Available for download on the App Store and Google Play.
Manufacturer information
SANELA spol. s r. o.
Practical help
Common problems
Sensor not detecting users
Ensure the reflective foil is correctly installed and within the 0.3 - 3 m range.
Need to adjust flush time
Use the Sanela Control app via Bluetooth or the SLD 03 remote control.
Low battery
The system includes battery status monitoring; replace with 4x AA alkaline batteries (SLA 36).
Before use
- Verify water pressure is between 0.15 and 0.6 MPa.
- Ensure the reflective foil is installed in the correct position.
- Download the Sanela Control app for initial configuration.
- Check that the water inlet cross-section is at least 32 mm.
- Install the 4 AA batteries provided.
Specs in practice
- Sensor range
- The distance the sensor can detect the reflective foil (0.3 to 3 meters).
Images and diagrams
- The diagram illustrates the placement of the stainless steel cover, installation boxes (plastic and stainless steel), and the reflective foil relative to the urinal.
- It highlights the connection points between the electronics and the valve.
Model compatibility
- Requires Sanela Control app or SLD 03 remote for parameter settings.
- Compatible with urinals requiring rear inlet (requires SLA 02 fitting).
