Taramps BASS 1K6 Loudspeaker Owner’s Manual
Access the official owner's manual for the Taramps BASS 1K6 loudspeaker. This guide provides technical specifications, recommended cabinet designs, product dimensions, and warranty terms to ensure optimal performance and longevity.
Quick answers from the manual
Quick answer
- The Taramps BASS 1K6 is a 12-inch loudspeaker with 400+400W RMS power. It requires professional installation and a 45-liter vented cabinet for optimal performance. p. 3
Key actions
- Install the speaker in a 45-liter vented box with two 3-inch ducts at 300mm depth. p. 3
Problems and fixes
Coil damage
Avoid excessive power or extreme distortion, which causes heating above 240°C.
p. 4Technical specifications
| Parameter | Value | Meaning | Pages |
|---|---|---|---|
| RMS Power | 400+400 W | Continuous power handling | p. 3 |
| Nominal Impedance | 2+2 or 4+4 Ohms | Speaker load | p. 3 |
| Weight | 8.5 kg | Total weight of the unit | p. 3 |
Where to find it in the PDF
- Technical Specifications and Dimensions p. 3
- Warranty Terms p. 4
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
The Taramps BASS 1K6 is a high-performance loudspeaker designed specifically for low-frequency reproduction. To ensure optimal performance and maintain warranty coverage, the product must be installed by a specialized professional. The speaker features a dual coil design, allowing for flexible connection configurations with amplifiers.
Technical specifications
The BASS 1K6 is built with the following electrical and mechanical parameters:
- RMS Power: 400+400 W
- Musical Program Power: 800+800 W
- Nominal Impedance: 2+2 or 4+4 Ohms
- Frequency Response: 20 to 1,000 Hz
- Sensitivity: 87.689 dB (@ 1W, 1m)
- Weight: 8.5 kg
- Coil Diameter: 2 1/2 inches
- Housing Material: Aluminum
Cabinet suggestions
For optimal sound reproduction, the manufacturer recommends a vented box configuration:
- Volume: 45 Liters
- Ducts Quantity: 02
- Duct Diameter: 3 inches
- Duct Depth: 300 mm
- Tuning (Syntony): 41.5 Hz
Warranty information
The product includes a 15-month warranty from the date of the invoice. To maintain this warranty, the following conditions must be met:
- The product must be installed correctly by a specialized professional.
- The original label with the serial number must be present on the product.
- The customer must present the invoice and the warranty term for service.
Warranty exclusions: The warranty does not cover damages caused by transport or handling accidents, humidity, improper installation, or coils burned due to excessive power or extreme distortion conditions (heating above 240°C).
Practical help
Common problems
Coil burning
Avoid excessive power input or extreme distortion conditions, which cause heating above 240°C.
Warranty void
Ensure the product is installed by a professional and that the original serial number label remains intact.
Before use
- Verify the amplifier impedance matches the speaker configuration (2+2 or 4+4 Ohms).
- Ensure the cabinet volume is built to the recommended 45 Liters.
- Have the installation performed by a specialized professional.
- Keep the original invoice and warranty certificate for future service needs.
Specs in practice
- Nominal Impedance
- The electrical load the speaker presents to the amplifier, crucial for matching.
Images and diagrams
- The dimensions diagram shows the mounting depth (147.0mm) and outer diameter (317.0mm) required for installation.
- The cabinet suggestion table provides the exact volume and port dimensions required for the vented box design.
Model compatibility
- Designed for low-frequency reproduction.
- Requires a vented box enclosure of 45 Liters for best performance.
