Wampler Metaverse Delay Pedal Quick Reference Guide
Quick reference guide for the Wampler Metaverse programmable delay pedal. Learn how to use program selectors, primary controls, alternate functions, and connection settings.
Table of contents
Quick guide from the manual
The Wampler Metaverse is a programmable delay pedal. This guide covers the essential operations, including program selection, primary and alternate control functions, and connection requirements. Ensure you are using a 9V DC power supply with at least 130mA current draw.
Program Selector
Use the Program Selector to choose between 11 different delay types:
- ANLG: Analog delay
- WET: Modulated analog
- BBD: Bucket Brigade delay
- JET: Analog flanger delay
- DOC: The Doctor
- FTE: Faux Tape Echo
- ETH: Ethereal
- MOD: Digital flanger delay
- SPC: Echo-Space delay
- TAPE: Multi-head tape delay
- DIGI: Digital delay
Primary Controls
The primary knobs control the core sound of the delay:
- Delay: Sets delay time between 25ms (CCW) and 2000ms (CW).
- Mod: Sets modulation depth (CCW lowest, CW highest).
- Feedback: Sets delay feedback (CCW lowest, CW highest).
- Mix: Sets dry/wet signal mix. 0% is 100% dry, 75% is 100% dry + 100% wet, 100% is 100% wet.
- Tone: Sets delay tone.
Alternate Functions
To access alternate functions on the knobs, hold down the Bypass Switch (the LED will turn red). Alternate functions include:
- Delay Knob: Sets modulation rate for all effects.
- Mod Knob: Sets modulation rate for all effects.
- Feedback Knob: Selects head combination (TAPE mode) or Ethereal mode (ETH mode).
- Mix Knob: Sets total output level (0% = -6dB, 50% = 0dB, 100% = +6dB).
- Tone Knob: Sets modulation feedback for JET and MOD programs.
Switches and Presets
- Bypass Switch: Turns the delay effect on/off. Hold to access alternate knob functions.
- Preset Switch: Increments presets. Hold to initiate save. When bypass is held, it selects subdivisions.
- Tap Tempo Switch: Triggers tap tempo (LED blue) or increments presets (LED green). Hold for 1 second to toggle modes. Pressing this switch exits Preset save mode.
Connections and Power
- Power: 9V DC only, 130mA.
- MIDI: Input/Output via 3.5mm TRS.
- Expression: 1/4 inch Expression Pedal Input.
- I/O: Mono or Stereo Input and Output jacks.
- Trails Switch: Selects between True Bypass (left) and Trails (right).
Practical help
Common problems
Cannot access alternate knob functions
Hold down the Bypass switch; the LED will turn red to indicate you are in alternate function mode.
Need to save a preset
Hold the Preset switch to initiate the save process.
Need to change Tap Tempo modes
Hold the Tap Tempo switch for 1 second to toggle between Tap Tempo and Preset increment modes.
Exiting Preset save mode
Press the Tap Tempo switch.
Before use
- Ensure power supply is 9V DC and provides at least 130mA.
- Use 3.5mm TRS cables for MIDI connections.
- Use 1/4 inch cables for Expression pedal and audio I/O.
- Set the Trails Slide Switch to your preference (True Bypass or Trails).
Specs in practice
- Output Level (Alt)
- Adjustable via Mix knob in Alt mode: 0% = -6dB, 50% = 0dB, 100% = +6dB.
Images and diagrams
- The main diagram illustrates the pedal interface, showing the location of the Program Selector, primary knobs, switches, and input/output jacks.
- The diagram highlights the dual-function nature of the knobs (Primary vs. Alt) and switches.
Model compatibility
- Supports both Mono and Stereo input/output configurations.
- MIDI Input/Output requires 3.5mm TRS connections.
- Compatible with standard 1/4 inch expression pedals.
