User Manual for Anker PowerExpand 8-in-1 USB-C PD 10Gbps Data Hub

At a Glance

The Anker PowerExpand 8-in-1 USB-C PD 10Gbps Data Hub is designed to expand the connectivity of your MacBook or compatible USB-C device. It features multiple ports for data transfer, video output, and power delivery.

Port Descriptions

The device includes the following ports and indicators:

• 1. USB-C Connector: Plugs into the MacBook's USB-C port.
• 2. PD-IN Port: Connects to a USB-C PD charger to charge your connected devices.
• 3. USB-C Port: Supports data transfers up to 10 Gb/s.
• 4. HDMI Port: Connects to a device with an HDMI port to stream video at resolutions up to 4K@60 Hz.
• 5. Ethernet Port: Connects to a router or modem at 10/100/1000 Mbps.
• 6. Power Indicator: Turns white when the hub is powered on.
• 7. SD Card Slot: Supports SD 3.0 cards for file transfer.
• 8. microSD Card Slot: Supports microSD cards for file transfer.
• 9. USB-A Port: Connects to USB-A devices for data transfer up to 10 Gb/s.

Usage Instructions

To use the hub, simply plug the USB-C connector into your computer's USB-C port. The power indicator will light up white. You can then connect your peripherals (HDMI, Ethernet, USB-A, SD/microSD cards) to the respective ports. For charging your laptop, connect a USB-C PD charger to the PD-IN port.

Safety Instructions

To ensure safe operation, please follow these guidelines:

• Avoid dropping: Do not subject the product to physical impact.
• Do not disassemble: Do not attempt to open or repair the device yourself.
• Do not expose to liquids: Keep the device dry at all times.
• Use certified cables: For the safest and fastest charging, use original or certified cables.
• Temperature limits: This product is suitable for moderate climates only. The maximum ambient temperature during use must not exceed 40°C (104°F).
• Open flames: Do not place open flame sources, such as candles, near the product.
• Cleaning: Use only a dry cloth or brush to clean the product.

Specifications

The hub supports the following technical specifications:

• Data Speed: Up to 10 Gbps.
• Supported Systems: Windows 10 / 8 / 7 / Vista / XP, Mac OS X 10.2 and above, Chrome OS.
• Dimensions: 121 × 55 × 15.3 mm / 4.7 × 2.2 × 0.6 in.
• Weight: 109g / 3.8 oz.

Customer Service

For FAQs and more information, visit anker.com/support. You can also contact Anker via email at [email protected] or by phone using the numbers provided in the manual for your specific region.
