User Manual for Arenti Speed 10T IP Camera
Quick start guide and user manual for the Arenti Speed 10T IP Camera. Includes setup instructions, LED status indicators, technical specifications, and troubleshooting tips.
Table of contents
Manual images
Click an image to enlargeQuick guide from the manual
This guide provides the essential steps to set up and operate your Arenti Speed 10T IP Camera. The device is designed for indoor use and supports integration with Amazon Alexa and Google Assistant. Ensure you have a stable Wi-Fi connection and the Arenti app installed on your smartphone to begin the configuration process.
Product overview
The camera features several key components for operation:
- LED indicator: Displays the connection status.
- Microphone: For two-way audio communication.
- Micro SD card slot: Supports storage up to 128GB.
- Reset button: Used to restore factory settings.
- DC5V USB port: For power supply.
Device configuration
- Power on: Connect the camera to a power outlet using the provided power adaptor.
- Network connection: Ensure your smartphone is connected to your local Wi-Fi network.
- App installation: Download the Arenti app from the App Store or Google Play.
- Account setup: Launch the Arenti app and sign up for a new account.
- Add camera: Follow the in-app instructions to add your device. Keep your phone near the router during this process for the best signal.
LED status indicators
The LED light on the camera provides visual feedback regarding its status:
- Flashing red light (slow): Waiting for configuration.
- Flashing red light (fast): Searching for Wi-Fi network.
- Fixed blue light: Camera is connected to Wi-Fi.
- Flashing blue light: Access point mode.
Important notes
- Resetting: To reset the device, press and hold the reset button for 5 seconds. The camera will beep when the operation is complete.
- Multiple cameras: If you have multiple cameras, repeat the configuration steps for each device.
- Changing Wi-Fi: To change the Wi-Fi network, you must restore the camera to factory settings and perform the configuration process again.
Technical specifications
The Arenti Speed 10T offers the following technical capabilities:
- Resolution: 2 Mega pixels (1920 x 1080).
- Sensor: 1/2.9" CMOS.
- Night vision: Infrared distance up to 10 meters.
- Storage: Micro SD card (Max 128GB).
- Audio: Two-way audio.
- Wi-Fi: IEEE802.11a/b/g/n (2.4GHz + 5GHz).
- Operating temperature: -10°C to 45°C.
- Power: DC5V, 1A.
Manufacturer information
Arenti
Practical help
Common problems
Device not connecting to Wi-Fi
Ensure you are near the router for the best signal during the initial setup process.
Need to change Wi-Fi network
Restore the camera to factory settings by holding the reset button for 5 seconds, then follow the configuration steps again.
Camera status is unclear
Check the LED indicator. A flashing red light (slow) means it is waiting for configuration, while a fixed blue light means it is connected.
Before use
- Verify all items are in the box: Camera, Screws, USB cable, Power adaptor, Bracket, and Quick start guide.
- Download the Arenti app from the App Store or Google Play.
- Ensure your smartphone is connected to the Wi-Fi network you intend to use for the camera.
- Power on the device using the provided power adaptor.
Specs in practice
- Infrared distance
- The camera can see up to 10 meters in low-light conditions using high-power LEDs.
- Wi-Fi Frequency
- Supports both 2.4GHz and 5GHz bands for flexible network connectivity.
Images and diagrams
- The product description diagram identifies the location of the LED indicator, microphone, Micro SD card slot, reset button, and DC5V USB port.
Model compatibility
- Compatible with Amazon Alexa and Google Assistant.
- For indoor use only.
