User Manual for Avantco 177EBS100 and 177EBS102 Electric Portable Hot Plates

Quick guide from the manual

The Avantco 177EBS100 and 177EBS102 are electric portable hot plates designed for commercial use. Before first use, you must perform a burn-off process by heating the unit at the maximum setting for 5 minutes without a pot. Note that these units are designed for pan frying, sautéing, or simmering, and are not designed for boiling or for use with saucepots over 2 quarts.

Important Safety Information

• Indoor use only.
• Always place the unit on a flat, level, heat-resistant surface.
• Do not operate with a damaged cord or plug.
• Keep cords and plugs away from water and other liquids.
• Do not place metal utensils or oversized foods on the unit.
• Do not cover the unit with metal foil.
• Always unplug the unit when not in use and before cleaning.
• Allow the unit to cool completely before cleaning or moving.

Installation

Ensure the unit is installed in a non-combustible location. Maintain a clearance of at least 8 inches from combustible materials on the sides, front, and rear, and 40 inches above the appliance.

• Unbox the hot plate and remove the plastic coating from all stainless-steel surfaces.
• Ensure all rubber feet are installed properly.
• Check that the voltage of your outlet matches the unit requirements.

Operating Instructions

1. Ensure the control knob is in the OFF position before plugging the unit into a standard 120V AC outlet.

2. Place cookware onto the heating element.

3. Adjust the control knob to the desired heat level (Lo to Hi).

4. To turn off, rotate the control knob to the OFF position and unplug the unit.

Care and Maintenance

Always ensure the unit is unplugged and cooled down before cleaning. Use a damp cloth or sponge with a mild detergent to clean the surfaces. Do not immerse the product in liquid, do not place it in a dishwasher, and do not use abrasive cleaners or pads.

Troubleshooting

If the unit fails to operate, check the following:

• Is the unit connected to a live power source?
• Check the circuit breaker.
• Is the power switch on and the pilot light glowing?
• Check the data plate to ensure you are operating on the proper voltage.
