Danfoss 027F0561 Overhaul Kit Installation Guide
A comprehensive guide to the Danfoss 027F0561 Overhaul Kit for PML size 100 valves. Includes an exploded view diagram, parts list, material specifications, and component quantities for maintenance.
Table of contents
Important Information
This document serves as the official parts list and assembly reference for the Danfoss 027F0561 Overhaul Kit, specifically intended for PML size 100 valves. It provides an exploded view of the valve assembly and details the specifications for all included components.
Overview of the Overhaul Kit
The overhaul kit contains a set of seals, gaskets, and internal components required for valve maintenance. Users should refer to the exploded view diagram to identify the correct placement of each part within the valve assembly.
Parts Identification and Specifications
The components are numbered 1 through 24. Each part is specified by its material type (Aluminum or Fibre) and dimensions in both millimeters (mm) and inches (in). The total quantity for each part is also provided.
- Material Types: Components are categorized as either Alu. (Aluminum) or Fibre (Fiber-based material).
- Dimensions: Measurements are provided for diameter to ensure correct part selection.
- Quantities: The Total no. field indicates how many of each specific part are required for the assembly.
Maintenance Notes
Please note that some parts included in the package are marked with an asterisk (*). These specific parts are included in the kit but are not used for the PML size 100 configuration. Ensure you verify the requirements for your specific valve size before installation.
Manufacturer information
Danfoss A/S
Practical help
Common problems
Parts marked with an asterisk (*) are included in the kit.
These parts are not used for the PML size 100 valve configuration and should be set aside.
Before use
- Verify the kit code is 027F0561.
- Confirm the valve model is PML size 100.
- Organize all parts according to the exploded view diagram before starting maintenance.
- Check the material type (Alu. or Fibre) for each seal or gasket.
Images and diagrams
- The exploded view shows the internal structure of the valve and the relative positioning of all components numbered 1 through 24.
Model compatibility
- This kit is specifically for PML size 100 valves.
- Parts marked with an asterisk (*) are not compatible with PML size 100.
