Installation Guide for Danfoss PML Size 125 Overhaul Kit
Installation guide and spare parts reference for the Danfoss PML size 125 overhaul kit. Includes an exploded view diagram and component specifications for maintenance.
Table of contents
Quick guide from the manual
This document serves as the installation and spare parts reference for the Danfoss PML size 125 overhaul kit (Code number 027F0562). It provides an exploded view of the valve assembly and a detailed list of components required for maintenance.
Component Assembly
The provided diagram illustrates the internal structure of the PML valve. Use the numbered references in the diagram to identify specific parts during the overhaul process. Ensure all components are correctly oriented according to the assembly view before finalizing the installation.
Spare Parts Identification
The overhaul kit includes various components labeled 1 through 24. The manual specifies the material type for each part:
- Alu. (Aluminum): Used for specific seals and components.
- Fibre: Used for gaskets and sealing rings.
Each part is listed with its corresponding dimensions (in mm and inches) and the total quantity required for the assembly.
Important Notes
Please note the following regarding the kit contents:
- Parts marked with an asterisk (*) in the documentation are included in the package but are not used for the PML size 125 model.
- Verify all part numbers and material types against the provided table before installation to ensure compatibility with your specific valve unit.
Manufacturer information
Danfoss A/S
Practical help
Before use
- Verify the valve model is PML size 125
- Confirm the overhaul kit code is 027F0562
- Identify parts marked with an asterisk (*) and exclude them from the PML 125 assembly
- Check material types (Alu vs Fibre) for correct placement of seals
Images and diagrams
- The main diagram shows an exploded view of the PML valve assembly
- Numbers in the diagram correspond directly to the spare parts list table
Model compatibility
- Parts marked with an asterisk (*) are included in the package but are not used for PML size 125
