This document provides user instructions for two separate JBL products: the Vibe 100TWS True Wireless Earbuds and the GO2 Ultra Portable Waterproof Speaker. Please refer to the specific section for your device.
JBL Vibe 100TWS Earbuds
Features
- JBL Deep Bass Sound: Powered by 8mm drivers.
- 20 Hours Combined Playback: 5 hours in earbuds and 15 hours in the charging case.
- Dual Connect: Use either earbud independently or both together.
- Hands-free Calls: Manage calls and voice assistant directly from the earbuds.
- Comfort-fit: Ergonomic design with 3 sizes of ear tips.
Technical Specifications
- Driver size: 8mm Dynamic Driver
- Power supply: 5V 1A
- Charging time: 2 hours from empty
- Bluetooth version: 5.0
- Frequency Response: 20Hz – 20kHz
- Weight: 46.3g (total)
JBL GO2 Speaker
Buttons and Connections
The speaker features top-mounted buttons for Power, Bluetooth, Volume Down, Volume Up, and Play/Pause/Call. The side panel contains the Aux input and Micro USB charging port.
Bluetooth Pairing
To connect, press the Bluetooth button on the speaker and select 'JBL GO2' in your device's Bluetooth settings.
LED Indications
- Slow blinking blue: Not connected.
- Fast blinking blue: Pairing mode / Incoming call.
- Solid blue: Connected.
- Blinking red: Low power.
- Solid red: Charging.
Waterproof Usage (IPX7)
The JBL GO2 is IPX7 waterproof, meaning it can be immersed in water up to 1 meter for up to 30 minutes. Important: To ensure waterproofing, remove all cable connections and tightly close the port cover. Exposing the speaker to liquids without doing so may result in permanent damage.
Technical Specifications
- Bluetooth version: 4.1
- Rated power: 3.1W RMS
- Frequency response: 180Hz – 20kHz
- Battery type: Lithium-ion polymer (3.7V, 730mAh)
- Music playtime: Up to 5 hours
- Charging time: 2.5 hours
Manufacturer information
JBL
Practical help
Common problems
Speaker not waterproof
Ensure all cable connections are removed and the port cover is tightly closed before exposing to water.
Battery not charging
Check if the charging cable is connected properly and the power source is active.
Bluetooth pairing failure
Ensure the speaker is in pairing mode (fast blinking blue LED) and check your device's Bluetooth settings.
Before use
- Charge the device fully before first use.
- For GO2, ensure the port cover is closed before water exposure.
- Pair via Bluetooth settings on your phone.
- Select the correct ear tip size for the Vibe 100TWS for optimal sound.
Specs in practice
- Dual Connect
- Allows using either earbud independently or both together.
Images and diagrams
- GO2 Buttons: Power, Bluetooth, Volume -, Volume +, Play/Pause/Call.
- GO2 Connections: Aux input and Micro USB charging port.
Model compatibility
- Vibe 100TWS uses Bluetooth 5.0.
- GO2 uses Bluetooth 4.1.
