User Manual for Ningbo 056T Remote Control Transmitter

Quick guide from the manual

The Ningbo 056T is a 5-channel remote control transmitter designed to operate compatible radio-controlled power outlets. Before use, ensure the CR2032 battery is correctly installed with the positive pole facing upward. The remote features two columns of keys: the left column activates channels 1-5, and the right column deactivates them. The device operates at 433.92 MHz with a range of up to 50 meters in open areas.

Operating elements

• 1. Indicator lamp: Lights up when a key is pressed.
• 2. Control keys: Arranged in two columns for ON/OFF functions.
• 3. ALL ON/ALL OFF key: Activates or deactivates all 5 channels simultaneously.
• 4. Buckle of compartment: Used to access the battery.

Inserting/replacing battery

1. Hold down both ends of the battery compartment (4) and push it outward forcefully.
2. Remove the insulating sheet (if present) or insert one CR2032 round cell battery into the recess.
3. Ensure the positive pole faces upward (check the “+” imprint).
4. Push the battery fully into the recess and close the compartment.

Note: Replace the battery if the remote's range decreases noticeably or if the indicator lamp (1) fails to light when a button is pressed.

Key functions

• Control keys (2): The left column turns channels 1 to 5 ON; the right column turns them OFF.
• ALL ON/OFF keys: Use these to activate or deactivate all channels 1 to 5 together.

Operation

Configuration and dimming functions depend on the specific radio-controlled power outlet you are using. Refer to the operating instructions of your power outlet for pairing details. This remote can control an unlimited number of compatible radio-controlled power outlets.

Technical data

• Battery type: 3V CR2032
• Number of channels: 5 individual channels + All ON/OFF channels
• Transmission frequency: 433.92 MHz
• Transmission range: Max. 50 m (in open area)
• Dimensions: 115 x 37 x 13 mm
• Weight: 30.5 g

Safety Warnings

WARNING: This product contains a button cell or coin battery. Ingestion can cause death or serious injury, including internal chemical burns in as little as 2 hours. Keep batteries away from children. Do not mix old and new batteries or different types. If the battery compartment does not close securely, stop using the product and remove the batteries.
