Sealey MAC13D 12V/230V Tyre Inflator and Air Compressor User Guide
Quick guide for the Sealey MAC13D dual-power tyre inflator and air compressor. Includes setup, operation for high and low-pressure items, LED light modes, and maintenance instructions.
Table of contents
Manual images
Jump to the sectionQuick guide from the manual
The Sealey MAC13D is a dual-power (12V DC and 230V AC) tyre inflator and high-volume air pump. It features an auto-shut-off function when the pre-set pressure is reached, a digital display, and an integrated LED worklight. Always monitor the pressure gauge during operation and avoid continuous use for more than 15 minutes to prevent overheating; a 10-minute rest period is recommended.
Operation
High Pressure Items (Tyres):
- Connect to the power source (12V DC or 230V AC).
- Attach the valve adaptor to the item and lock it.
- Press the power button, select the desired pressure unit using the M button, and set the pressure with + or -.
- Start inflation using the mode button. The unit will stop automatically at the set pressure.
Low Pressure Items (Mattresses/Inflatables):
- Connect the high-volume hose to the air outlet (for inflation) or inlet (for deflation).
- Secure the hose to the item.
- Start the unit and select the appropriate mode.
- Important: You must manually turn off the pump when the desired pressure is reached for low-pressure items.
LED Light
Press the LED light button to cycle through three modes: steady bright light, flashing red, and red SOS signal.
Maintenance
- Keep the device clean and dry.
- Clean surfaces only with a soft, damp cloth; do not submerge in water.
- Check for damaged parts weekly.
- To replace the fuse in the 12V plug, unscrew the top with long-nose pliers, replace the fuse, and reassemble.
- For any repairs or if the unit becomes unserviceable, contact the Sealey Service Centre.
Manufacturer information
Sealey Group
Practical help
Common problems
Unit overheating
Do not exceed 15 minutes of continuous run time; allow a 10-minute rest period.
Low pressure item over-inflation
The auto-shut-off feature does not apply to low-pressure mode; you must manually turn off the unit.
Damaged power cord
Must be replaced by the manufacturer or a qualified person to avoid hazards.
Before use
- Inspect power leads and plugs for wear or damage.
- Ensure the voltage rating matches your power supply.
- Check the maximum capacity of the item to be inflated.
- Ensure the compressor is placed on an appropriate surface.
- Verify that all parts are present and in good condition.
Specs in practice
- Maximum Pressure
- 120psi (8.3bar) limit for high-pressure items.
- Continuous Working Time
- Maximum 30 minutes before requiring a rest period.
Images and diagrams
- The unit features a digital display, mode selection buttons, and dedicated ports for high-pressure and high-volume hoses.
- Accessories including a Presta adaptor, ball spike, and tapered nozzle are stored on the housing.
Model compatibility
- Suitable for cars, vans, 4x4s, motorcycles, and bicycles.
- High-volume function is designed for air mattresses and inflatables.
