Owner's Manual for Bauer 19161P-B Forced Air Propane Portable Heater

Comprehensive user guide for the Bauer 19161P-B propane heater. Includes safety instructions, setup, operation procedures, maintenance, and parts diagram.

Quick answers from the manual

Quick answer

  • The Bauer 19161P-B is a forced air propane heater for construction use. It requires a 120VAC power source and a propane tank (not included). Always perform a leak test before use. p. 1, 11

Key actions

  • Perform a leak test p. 11
  • Start the heater p. 11

First start

  • Setup and connection p. 11

Problems and fixes

Burner fails to light

Close Gas Knob, wait 5 minutes for gas to dissipate, then retry.

p. 11

Maintenance and reset

  • Annual inspection p. 12

Technical specifications

Parameter Value Meaning Pages
Input Rating 39,000 - 64,000 btu/h Heat output capacity p. 9
Gas Supply Pressure 25 - 250 PSI Required propane tank pressure p. 9

Where to find it in the PDF

  • Safety Information p. 1, 2, 3, 4
  • Setup and Operation p. 10, 11
  • Maintenance and Parts p. 12, 14
Table of contents

Manual images

Click an image to enlarge
Bauer Forced Air Propane Heater - Front View Page 10 Exploded parts diagram Page 14

Quick guide from the manual

This manual provides essential safety, setup, and operation instructions for the Bauer 19161P-B Forced Air Propane Portable Heater. This device is designed for construction use only and is not for home or recreational vehicle use. Always prioritize safety by ensuring proper ventilation and keeping the heater away from flammable materials.

Safety Warnings

  • Gas Leaks: If you smell gas, immediately extinguish all flames, shut off the gas supply, and evacuate the area. Do not touch electrical switches.
  • Carbon Monoxide: Never use indoors, in tents, campers, or garages. Use only outdoors in well-ventilated areas.
  • Fire Hazard: Keep the heater at least 15 feet away from flammable objects. Do not store extra propane tanks near the heater.
  • Operation: Do not move the heater while it is in operation or hot. Wait 30 minutes for it to cool down.

Setup and Connection

Before using the heater, ensure it is placed on a level, stable, and fireproof surface. The propane tank must be located at least 6 feet behind the heater.

Bauer Forced Air Propane Heater - Front View
Bauer Forced Air Propane Heater - Front View
Exploded parts diagram
Exploded parts diagram

Connecting the Propane Tank

  1. Close the gas valve on the propane tank and the Gas Knob on the heater.
  2. Connect the hose to the propane tank and the heater.
  3. Perform a leak test by applying soapy water to all joints and fittings. If bubbles expand, a leak is present; do not use the heater until fixed.

Operation

Starting the Heater

  1. Plug the power cord into a grounded 120VAC outlet.
  2. Turn the Power Switch on and let the fan run for 30 seconds.
  3. Slowly open the gas valve on the propane tank, then open the Gas Knob on the heater a quarter turn.
  4. Position yourself behind the heater.
  5. Push and hold the Gas Valve on the left side.
  6. Push and hold the Ignition Button on the right side until the burner lights.
  7. Release the Ignition Button, but continue holding the Gas Valve for 5 seconds.
  8. Release the Gas Valve and adjust the Gas Knob as necessary.

Stopping the Heater

  1. Close the gas valve on the propane tank.
  2. Close the Gas Knob on the heater.
  3. Let the fan run for 2 minutes to cool the unit.
  4. Turn the Power Switch off and unplug the heater.
  5. Disconnect the hose.

Maintenance

  • Before Each Use: Inspect for loose hardware, damaged hoses, or gas leaks.
  • After Use: Wipe external surfaces with a clean cloth.
  • Annual Inspection: Have the heater inspected by a qualified technician once a year.
  • Storage: Store in a safe, dry, covered place out of reach of children. Ensure the propane tank is disconnected and stored separately.

Practical help

Common problems

Smell of gas

Immediately shut off gas, extinguish flames, evacuate the area, and call your gas supplier.

Burner does not light within 30 seconds

Close the Gas Knob, wait at least 5 minutes for gas to dissipate, then repeat the lighting process.

Heater shuts off during operation

Close the gas valve, check the gas level in the tank, and wait 5 minutes before attempting to restart.

Before use

  • Ensure the heater is on a level, stable, fireproof surface.
  • Verify the propane tank is at least 6 feet away from the heater.
  • Perform a leak test using soapy water on all connections.
  • Remove all packing materials.
  • Ensure proper ventilation is available.
  • Wear ANSI-approved safety goggles.

Specs in practice

Input Rating
39,000 - 64,000 BTU/h
Minimum Ambient Temperature
14°F (-10°C)
Gas Supply Pressure
25 - 250 PSI

Images and diagrams

  • Exploded view of the heater showing all internal components.
  • Parts list table identifying components by number.

Model compatibility

  • Use only with HD-5 propane gas.
  • Use only with a vapor withdrawal LP propane tank equipped with a POL valve.
  • Do not use bulk tanks of larger capacity than 20 lbs.
