Hansgrohe Raindance Alive Q 210/340 1jet EcoSmart Overhead Shower Specification Sheet
Technical specifications, flow diagrams, and spare parts list for the Hansgrohe Raindance Alive Q 210/340 1jet EcoSmart overhead shower. Includes details on spray modes, water consumption, and maintenance.
Table of contents
Manual images
Click an image to enlargeQuick Guide from the Manual
The Hansgrohe Raindance Alive Q 210/340 1jet EcoSmart is a high-quality overhead shower designed for efficiency and comfort. This document provides technical specifications, flow performance data, and a spare parts breakdown to assist with maintenance and installation planning.
Product Description
The shower features a minimalist, flat design with an anodized aluminum cover. Key features include:
- Spray Modes: Supports Rain and PowderRain spray types. The spray type can be selected during installation or changed later.
- EcoSmart Technology: Limits water consumption to a maximum of 8 l/min, ensuring water efficiency without compromising comfort.
- DropGuard: A specialized feature that reduces post-shower dripping to just a few seconds.
- Adjustability: The angle of the overhead shower is adjustable.
- Maintenance: The design cover is removable without tools, allowing for easy cleaning of the spray nozzles.
Technical Specifications
The following technical data applies to the Raindance Alive Q 210/340 1jet EcoSmart:
- Spray Plate Diameter: 214 x 343 mm
- Flow Rate (at 3 bar): Max 8 l/min (with -20% tolerance)
- PowderRain Flow Rate (at 3 bar): 6.7 l/min
- Connection: G 1/2
- Surface: Graphite spray plate and design cover
Maintenance and Cleaning
To maintain optimal performance, the design cover can be removed without the use of tools. This allows direct access to the spray nozzles for cleaning. Ensure that the shower is kept free of limescale buildup to maintain the intended spray pattern and flow rate.
Spare Parts
The document includes an exploded view and a list of spare parts for the unit. Key components include the diverter (omstelling), seals (dichting), sieve (zeef), flow limiter (doorstroombegrenzer), and the cover (afdekkap). These parts are essential for any necessary repairs or maintenance.
Manufacturer information
Hansgrohe SE
Practical help
Common problems
Reduced water flow
Check the flow limiter and the sieve for debris or limescale buildup.
Dripping after shower is turned off
The DropGuard feature minimizes this; however, some residual water is normal. If dripping is excessive, check the seal.
Before use
- Verify that the water pressure is sufficient for the shower system.
- Ensure the G 1/2 connection is properly sealed.
- Check that the spray plate is clean and free of obstructions.
- Confirm the desired spray mode (Rain or PowderRain) is set.
Images and diagrams
- The flow diagram illustrates the relationship between water pressure (MPa/Bar) and flow rate (l/min).
- The exploded view identifies the internal components for maintenance and part replacement.
Model compatibility
- Designed for standard G 1/2 plumbing connections.
