LeoVince 14454EU LV One EVO Slip-On Exhaust Installation Guide
Quick installation guide for the LeoVince 14454EU/14454EBU LV One EVO slip-on exhaust for Moto Guzzi V85 TT. Includes component lists, step-by-step mounting instructions, and maintenance tips.
Table of contents
Manual images
Jump to the sectionQuick guide from the manual
This document provides installation and maintenance instructions for the LeoVince LV One EVO slip-on exhaust (Art. 14454EU / 14454EBU) designed for the Moto Guzzi V85 TT. The exhaust is compatible with the 35kW version, original panniers, and the original centre stand. Professional installation is highly recommended.
Installation
- Remove the original silencer(s) and collector pipe(s).
- Insert the provided bushing into the stock manifold.
- Insert the LeoVince link pipe between the stock manifold and the LeoVince bushing.
- Fit the clamp(s) onto the LeoVince silencer(s) and install the silencer(s).
- Mount spacers, washers, and brackets as shown in the technical drawing.
- Secure all parts using the provided or original bolts.
- Connect the components using the supplied springs or clamps.
- Install the heat shield(s).
- Check the alignment of all components, ensure all fasteners are tightened, and start the engine. Allow it to reach operating temperature and check for any gas leaks.
Maintenance
Periodically check all brackets and fasteners, as they may be affected by use. Inspect sound-deadening material, seals, and rubber parts, and replace them if necessary. The silencer can be cleaned with gasoline, diesel oil, or alcohol; do not use any solvents. Discolouration of the silencer is normal due to heat and material properties.
Important Warnings
- Ensure the exhaust surface is completely cool before starting any work to avoid burns or damage to heat-sensitive components.
- During the first few kilometres, the exhaust system will undergo a break-in period; slight gas leakage may occur.
- After approximately 100 km, re-check and tighten all fasteners.
- White smoke may appear during the first use, even after the engine is turned off; this is normal.
- Any modification or tampering with the silencer is strictly prohibited and voids all responsibility from Belgrove Sp. z o. o.
Manufacturer information
LeoVince
Practical help
Common problems
Slight gas leakage during first use
This is normal during the break-in period. Check and tighten all fasteners after 100 km.
White smoke appearing from exhaust
This is normal during the first use as the system settles.
Discolouration of the silencer
This is a normal result of heat and material properties and is not a defect.
Before use
- Ensure the engine and exhaust are completely cool.
- Verify all components from the supplied parts list are present.
- Use a rubber mallet if connection pipes need adjustment.
- Check that the motorcycle is in standard trim.
- Ensure the model year is >= 2024 if using the specific S.S. bushing.
Specs in practice
- Weight (Original)
- 5.39 kg
- Weight (LeoVince)
- 4.31 kg
Images and diagrams
- The technical drawings show the assembly sequence of the silencer, link pipe, and mounting hardware.
- Specific attention is required for the placement of spacers, washers, and the carbon clamp.
- The diagram highlights the use of the S.S. bushing for models from 2024 onwards.
Model compatibility
- Fits Moto Guzzi V85 TT (including 35kW version).
- Compatible with original panniers.
- Compatible with original centre stand.
